Wave solder machine
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Supply Ability: | 1 |
| Certificate: | 1 |
Product Description
Product Description
Specifications E-350
Dimension:L*W*H(mm) 4430 X 1620 X1650
Weight(kg) Approx.2300kg
Power Supply 3P5W,380/220V 50Hz 63A
Startup Power (kw) 26kw
Operation Power Consumption 10kw
Control System Computer+Siemens PLC
Spray System
Transmission Methed Air Cylinder/Step Motor(option)
Spray Pressure 0.25Mpa--0.4Mpa
Flux flow 10--100ml/min
Auto Fill Flux Standard
Exhaust Methed Up & Down Exhaust
Exhaust Ducting Diameter 200mm
Exhaust Capacity 25m3/min
Preheating System
Preheating Mode "IR Tube/Hot Air
(option)"
Control Mode PID + SSR
Preheating Zoon Number 4
Preheating Length 1800mm
Preheating Temp. "Room Temperature-
250"
Warm-up Time(min) Approx.15min (setting 150)
Conveyor System
PCB Width (L X W)(mm) Min:80x60mm; Max:500x350mm
Conveyor Direction LR;(RL)option
Conveyor Speed(mm/min) 0-2000
Conveyor Height (mm) 750+/-20
Available Component Height(mm) Top120mm/Bottom15mm
Conveyor Speed Control Mode Closed Loop
Finger Quick-change Finger(standard)
Conveyor Width Control Auto
Conveyor Angle 4~7angle
Soldering System
Solder Pot Style Motor Drive
Solder Pot Material Titanium alloy
Wave Height Adjust Digital Control by PC
Solder Pot Temperature 300
Solder Pot Capacity 400kg
Wave Drive Power 2kw 220v
Solder Por Warm-up Temperature Approx.180min(setting 250)
Cooling System
Cooling Method Forced Air/Airchiller(option)
Other
Finger Cleaning System Brush
Option
Centrer Support Option
Top Heating Option
Ups Protection Option
Nitrogen Device Option
Dimension:L*W*H(mm) 4430 X 1620 X1650
Weight(kg) Approx.2300kg
Power Supply 3P5W,380/220V 50Hz 63A
Startup Power (kw) 26kw
Operation Power Consumption 10kw
Control System Computer+Siemens PLC
Spray System
Transmission Methed Air Cylinder/Step Motor(option)
Spray Pressure 0.25Mpa--0.4Mpa
Flux flow 10--100ml/min
Auto Fill Flux Standard
Exhaust Methed Up & Down Exhaust
Exhaust Ducting Diameter 200mm
Exhaust Capacity 25m3/min
Preheating System
Preheating Mode "IR Tube/Hot Air
(option)"
Control Mode PID + SSR
Preheating Zoon Number 4
Preheating Length 1800mm
Preheating Temp. "Room Temperature-
250"
Warm-up Time(min) Approx.15min (setting 150)
Conveyor System
PCB Width (L X W)(mm) Min:80x60mm; Max:500x350mm
Conveyor Direction LR;(RL)option
Conveyor Speed(mm/min) 0-2000
Conveyor Height (mm) 750+/-20
Available Component Height(mm) Top120mm/Bottom15mm
Conveyor Speed Control Mode Closed Loop
Finger Quick-change Finger(standard)
Conveyor Width Control Auto
Conveyor Angle 4~7angle
Soldering System
Solder Pot Style Motor Drive
Solder Pot Material Titanium alloy
Wave Height Adjust Digital Control by PC
Solder Pot Temperature 300
Solder Pot Capacity 400kg
Wave Drive Power 2kw 220v
Solder Por Warm-up Temperature Approx.180min(setting 250)
Cooling System
Cooling Method Forced Air/Airchiller(option)
Other
Finger Cleaning System Brush
Option
Centrer Support Option
Top Heating Option
Ups Protection Option
Nitrogen Device Option
