LED npn-waterproof power supplier

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

LED Non-waterproof power supplier series:

1.built-in EMI filter

2.100% load test

3.Full range of input voltage

4.output voltage accurate and stable

5.Output over-voltage, over-current and short-circuit protection

6.Output low ripple and noise

7.One year warranty

8.Average working no trouble >50,000 hours

Product Electric Parameters
Input specification	Input voltage		AC110V/220V/±10%
	Input frequency		50/60Hz
	Input surge		20A,120VAC 40A,230VAC
Output specification	Output voltage can be adjusted		±10%
	Start-up time		leq1S(input230V,Io=100%)
	keep time		More than or equal to 20mS (input230V,Io=100%)
	Voltage regulation		(Full load) leq 0.5%
Protection function	Overload protection		105% - 150% rated power, automatic recovery
	Over-voltage protection		105% - 150% of the rated voltage
Insulation intensity	Input---output		1500VAC/1min
	Input---ground		1500VAC/1min
	Input---ground		500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN 60950-1 standards.
E M C standards	According with GB9254, EN55022 class A EN61347-2-13:2008 standards
Environmental	working temperature	- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature	- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level	leq2000M
Structure	Size(mm)	215(L)115(W)50(H)
Cooling method	Cooling method	Through the fan make temperature decrease
Weight	0.8KG/PCS
