LED Display Modules P2.5 Outdoor Advertising

LED Display Modules P2.5 Outdoor Advertising

As a professional led display screen,led video wall company, we can supply all kinds of led display screen customization service.

Regular indoor and outdoor led video wall modules,including outdoor p2.5 ,P3 P4 P5 P6 P8 P10 P16 etc and indoor P1.25 P1.5 P1.875 P2 P3 P4 P5 P10 etc. rental led video wall series including P3.91 P4.81 P2.6 P2.9 etc,

Now LED Display Screen Pixel pitch change to smaller and smaller , higher and higher definition. P2.5 led display screen led modules is a very newly technology, it have waterproof and high brightness features, it can suitable to outdoor environment. Especially to the small led display screen, fine pixel pitch p2.5 led display solved the definiton problems.

Would you install a small led digital signage? Come here to learn more details about outdoor fine pixel pitch p2.5 led display panels

Product Description

Pixel Pitch			P3.33mm	P4mm	P5mm	P6mm	P8mm	P10mm
LED Package			SMD1921	SMD1921	SMD2525	SMD3535	SMD3535	SMD3535
Module Size			320*160mm	256*128mm	320*160mm	192*192mm	256*128mm	320*160mm
Module Resolution			96*48dot	64*32dot	64*32dot	32*32dot	32*16dot	32*32dot
Cabinet Size			960*960mm	1024*1024mm	960*960mm	960*960mm	1024*1024mm	960*960mm
Cabinet Resolution			288*288dot	256*256dot	192*192dot	160*160dot	128*128dot	96*96dot
Cabinet Materials			steel cabinet	steel cabinet	steel cabinet	steel cabinet	steel cabinet	steel cabinet
Cabinet Wegiht			50KG/sqm	50KG/sqm	50KG/sqm	50KG/sqm	50KG/sqm	50KG/sqm
Brightness			>5000nits	>5000nits	>5000nits	>5000nits	>5000nits	>5000nits
Refresh Rate			>3840hz	>3840hz	>1920hz	>1920hz	>1920hz	>1920hz
Max Power Consumption			750W/sqm	720W/sqm	720W/sqm	720W/sqm	720W/sqm	720W/sqm
Ave. Power Consumptio			320W/sqm	320W/sqm	320W/sqm	320W/sqm	320W/sqm	320W/sqm
Operating Humidity			10% - 95%	10% - 95%	10% - 95%	10% - 95%	10% - 95%	10% - 95%
Certificate			CE,ROHS,FCC,ACMA
Life Span			>100,000 Hours
Input Source			HDMI, DVI, AVI, MPEG,VOB, RM, etc)
