TUV Approved solar cable 6mm
-
$0.50≥5000 Meter
- Min. Order:
- 5000 Meter
- Min. Order:
- 5000 Meter
- Transportation:
- Ocean
- Port:
- Shenzhen, Guangzhou
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 1 million/week |
| Supply Ability: | 1 million/week |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | ISO 9001 |
| HS Code: | 854449 |
| Transportation: | Ocean |
| Port: | Shenzhen,Guangzhou |
Solar Cable, PV1-F H1Z2Z2-K, specifically designed for use in solar power systems. It is made from a polyolefin copolymer material that has been cross-linked using electron-beam irradiation. This cross-linking process improves the cable's resistance to high temperatures, UV radiation, and other environmental factors commonly encountered in solar power applications.
Polyolefin copolymer electron-beam cross-linked solar cables are known for their excellent thermal stability and resistance to chemical degradation. They can withstand extreme temperatures, ranging from -40°C to 120°C, without compromising their performance. Additionally, these cables have a high level of UV resistance, ensuring that they can withstand prolonged exposure to sunlight without deteriorating.
These 4mm solar cable are typically used in photovoltaic (PV) systems, where they connect solar panels to inverters and other electrical components. They are designed to carry DC (direct current) power generated by the solar panels to the inverter, which converts it into AC (alternating current) for use in the electrical grid or powering appliances.
| Model Number | PV1-F H1Z2Z2-K |
| Standard: | IEC 62930 EN 50618 PPP 59074A |
| Approval | TUV SUD |
| Conductor | Tinned Flexible copper |
| Insulation | Polyolefin Copolymer electron-beam coss-linked |
| Sheath | Polyolefin Copolymer electron-beam coss-linked |
| Cores | Single core, Flat 2 cores |
| Rated voltage | AC1000V DC1500V DC 1800V |
| Temperature Rating | -40°C to 90°C ,More than 25 Years |
| Application | Solar PV system |
Approvals
Company Introduction:
BDK is a leading electrical supplies China manufacture, the main products include: Flexible Cables, LV Power Cable, Nyy Cables and other electric items.
The annual turnover reach USD 0.45 billion. We are the qualified supplier of State Power Grid, China Southern Power Grid and Vanke Group, Country Garden,ect and other large, medium partners around the world.
