3.5 inch 320x480 TFT display LCD screen TN-type
- Min. Order:
- 3000 Piece/Pieces
- Min. Order:
- 3000 Piece/Pieces
- Transportation:
- Ocean, Land, Air
- Port:
- ShenZhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | more |
| Supply Ability: | strong |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Transportation: | Ocean,Land,Air |
| Port: | ShenZhen |
Model Number: K350J2411B
Brand Name: Newvison
Origin: China (mainland)
Small Orders: Accepted
Key Specifications/Special Features:
LCM Dimension: 54.48(W)* 84.71(H) * 2.30(T) mm
LCD Active Area: 48.96* 73.44 mm
Number Of Dots: 320 * RGB * 480
LCD Type: a-Si TFT
Viewing Direction: 12 0'CLOCK
Driver IC: ST7796S
Interface Type: MCU
Operating Temperature: -20℃~ 70℃
Storage Temperature: -30℃~ 80℃
Backlight Type: 6 LEDs
Brightness: 370-400Cd/m2
Shipping Information:
- FOB Port: Shenzhen
- Lead Time: 20 - 25 days
- HTS Code: 9013.80.90 00
- Dimensions per Unit: 5.448 × 8.471 × 0.23 Centimeters
- Weight per Unit: 5.98 Kilograms
- Units per Export Carton: 260
- Export Carton Dimensions L/W/H: 38.5 × 31.5 × 22.7 Centimeters
- Export Carton Weight: 1.86 Kilograms
Main Export Markets:
- Asia
- Australasia
- Eastern Europe
- North America
- Western Europe
Any third-party trademarks or images shown here are for reference purposes only Organic Light Emitting Display. We are not authorized to sell any items bearing such trademarks 0.96 inch OLED.
When cleaning the TFT LCD screen, we usually need to pay attention to many things. Today, let the editor tell you some tips, I hope all users can master and use them flexibly Organic Light Emitting Diode.
1. Use alcohol or other chemical solvents to clean the TFT LCD screen. Currently, there is a special coating on the LCD screen. Once we wipe the display with alcohol, this special coating will dissolve, which will have an adverse effect on the display effect of the screen, and even damage the screen.
2. When wiping the LCD screen with ordinary cloth or paper towels, do not wipe the LCD screen with ordinary soft cloths (such as glasses cloth) or paper towels. For soft LCD screens, their surface is still a bit rough and easy to scratch.
3. When we clean the TFT screen with clean water, the liquid is easy to drip into the inside of the TFT screen, which will cause a short circuit of the device circuit board, which may burn out expensive electronic equipment.
4. When cleaning the TFT liquid crystal display, never use any alkaline solution or chemical solution to wipe the surface of the screen at will. The stains on the crystal plate can be roughly divided into two categories, one is the dust adhering to the air due to accumulation over time, and the other is the fingerprints or oil stains left by the user inadvertently. If you do not pay attention when cleaning the TFT LCD screen, it is easy to cause certain damage to the LCD. Thereby affecting the display effect and service life of the screen.
