What is a PCB connector?

With the development of higher transmission speed and smaller size of electronic equipment, Cable Connectors I/O Connectors also follow this trend, so chip connectors, optical fiber connectors, wired broadband connectors, and micro-pitch connectors are applicable Connector products for various portable/wireless electronic devices are expected to become star products in the future. On the other hand, with the rapid growth of China's consumer electronics, network design, communication terminal product output and the continuous transfer of global connector production capacity to China, China has become the world's fastest-growing and largest market for electronic connectors. PCB connector 　 The bottom contact connector has 4 to 8 circuit specifications, its rated current and voltage are 0.3A and 50V, and can be used for 0.12mm thick Rigid-Flex Board cables. It has a unique BackFlip clamp, which facilitates the insertion and extraction of cables in tight spaces, and has a super strong Rigid-Flex Board cable clamping force.

Its working principle is: usually on the insulating material, according to the predetermined design, made into the conductive pattern of the printed circuit, the printed element or the combination of the two is called the printed circuit. On the insulating base material, the conductive pattern of the electrical electronic connectors between the Electronic Components is provided, which is called the printed circuit. In this way, the printed circuit or the finished board of the printed circuit is called a printed circuit board, also called a printed circuit board or a printed circuit board.
2. PCB connector development trend
development trend:
miniaturization
Small size, light weight, small pitch, reduced height, high density/high pin number
High frequency signal/transmission
Low contact resistance, low inductance effect, good signal shielding effect, signal delay, Crosstalk... etc.
Automated operation
Reduction of station manufacturing process, Auto Pick & Place, SMT Type, product accuracy improvement, and maintenance methods
Humanized interface
User-friendly operation, fool-proof design
Low cost of use
Product standardization, flexible product and process design, delivery time reduction
3. PCB connector application
application:
PCB series connectors: used in military aviation, railway projects, industrial projects, aerospace projects, test instrument ship systems, electric sightseeing cars; UPS; communication power supplies; chargers, batteries and other products of choice for high-current connectors. The connector uses PBT material, which has good electronic and motor characteristics, and can be widely used in industrial needs.
All kinds of electric vehicles, electric buses, forklifts, golf carts, tourist vehicles, tractors, batteries, communication power supplies; UPS, AC and DC power supplies, EPS, inverters, high-frequency module power supplies, and high-frequency chargers Systems, electric machinery; electric wheelchairs, electric scrubbers, lawn mowers, vacuum cleaners, medical equipment, suction machines, decompression machines, electric treatment beds, power supplies, material handling equipment, rechargeable battery applications, power distribution equipment, and industrial equipment And other companies, and the Institute of Modern Physics of the Chinese Academy of Sciences jointly developed the Anen series of high-current connector products, which have been widely used in national large-scale electromechanical research and development projects and transportation, railway, and aerospace products.
