26GP-S2-ACR
Product Description
26GP-S2-ACR series unmanaged PoE switches, with 24 10/100/1000Mbps auto-adaptive RJ45 ports and 2 Gigabit optical ports. Each RJ45 port supports MDI/MDIX auto-flip and wire-speed forwarding. The store-and-forward method is adopted to provide stable and reliable data transmission.
Product parameters PRODUCT PARAMETERS
|
Provider Mode Ports |
||
|
Fixed port |
24*10/100/1000 Base-T +2* 1000Base-X |
|
|
Power interface |
AC220V |
|
|
LED Indicators |
PWR，link/active,speed(1000M) |
|
|
Optical fiber interface |
SFP |
|
|
Cable type&Transmission distance |
||
|
Twisted-pair |
0-100m |
|
|
Monomode optical fiber |
20/40/60/80/100KM |
|
|
Multimode optical fibre |
550M |
|
|
|
||
|
Network Topology |
||
|
Ring topology |
No support |
|
|
Star topology |
support |
|
|
Bus topology |
support |
|
|
Tree Topology |
support |
|
|
|
||
|
Electrical Specifications |
||
|
input voltage |
AC 100-240V 50/60Hz |
|
|
Total Power consumption |
≤400W （built-in power supply） |
|
|
|
||
|
PoE function |
||
|
Support standard |
802.3AF，802.3AT |
|
|
Power supply pin |
12+ 36- |
|
|
Support port |
1-24 |
|
|
|
||
|
DIP switch |
||
|
1 |
AI PoE( (Automatically detect port status and restart the remote PD) |
|
|
2 |
1-8口250M long distance transmission |
|
|
3 |
1-24 port isolation |
|
|
4 |
Storm suppression |
|
|
|
||
|
Layer 2 Switching |
||
|
Switching capacity |
52G |
|
|
Packet forwarding rate |
38.6Mpps |
|
|
8K |
||
|
Buffer |
4.1M |
|
|
<10us |
||
|
MDX/MIDX |
Support |
|
|
|
||
|
Environment |
||
|
Operating temperature |
-10℃~+50℃ |
|
|
Storage temperature |
-40℃~+70℃ |
|
|
Relative humidity |
5%~95% no support non-condensing |
|
|
Thermal methods |
Fanless design, natural heat dissipation |
|
|
MTBF |
100,000 hours |
|
|
|
||
|
EMC&INGRESS PROTECTION |
||
|
Surge protection of Ethernet port |
IEC 61000-4-5 Level 3（3/2KV）（10/700us） |
|
|
DIP） |
IEC 61000-4-11 Level3 （10V） |
|
|
ESD） |
IEC 61000-4-2 Level 4 （8K/15K） |
|
|
Free fall |
0.5m |
|
|
|
||
|
Mechanical Dimensions |
||
|
Product size |
440*285*44mm（LxWxH） |
|
|
Installation Method |
Rack-mounted |
|
|
Weight |
3.5KG |
|
|
Accessories |
|
|
|
Accessories |
Equipment, certificate, manual, power cord |
|
