MT FERRULE
-
$100.00≥1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
Your message must be between 20 to 2000 characters
Contact NowMT Ferrules Features
MT ferrules manufactured by high precision mold technology meet international standards such as IEC 61754-3-31, GR-135 etc.
MT Ferrule Dimensions
MT is short for mechanical transfer. MT ferrule is a multi-core polyphenylene sulfide ferrule, which is also called PPS ferrule, with a square end-face of 6.4×2.5 mm and 0.25mm pitch between adjacent fiber holes. The alignment mechanism includes two stainless steel guide pins that fit into precisely molded alignment holes.
As one of the professional ferrule supplier, T&S produces 12-core, 16-core and 24-core MT MPO ferrules at different grades like MM Standard, MM low loss and SM Standard and SM low loss.
MT MPO Ferrules Specifications
|
Ferrule Hole |
Type & Grade |
Fiber Hole Diameter (mm) |
Guide Pin Hole Diameter (mm) |
Insertion Loss（dB） |
|
MT-12 |
MM Standard MT Ferrule |
0.125+0.002/-0 |
0.7±0.001 |
Typical=0.25 max≤0.5 |
|
MM Low Loss MT Ferrule |
0.125+0.002/-0 |
0.7+0/-0.001 |
Typical=0.12 max≤0.35 |
|
|
SM Standard MT Ferrule |
0.125+0.0013/-0 |
0.7+0/-0.001 |
Typical=0.25 max≤0.7 |
|
|
SM Low Loss MT Ferrule |
0.125+0.0009/-0 |
0.6990+0.0006/-0 |
Typical=0.12 max≤0.35 |
|
|
MT-24 |
MM Standard MT Ferrule |
0.125+0.002/-0 |
0.7±0.001 |
Typical=0.25 max≤0.5 |
|
MM Low Loss MT Ferrule |
0.125+0.002/-0 |
0.7+0/-0.001 |
Typical=0.12 max≤0.35 |
|
|
SM Standard MT Ferrule |
0.125+0.0013/-0 |
0.7+0/-0.001 |
Typical=0.25 max≤0.7 |
|
|
SM Low Loss MT Ferrule |
0.125+0.0009/-0 |
0.6990+0.0006/-0 |
Typical=0.12 max≤0.35 |
|
|
MT-16 |
MM Standard MT Ferrule |
0.125+0.002/-0 |
0.55±0.001 |
Typical=0.25 max≤0.5 |
|
MM Low Loss MT Ferrule |
0.125+0.002/-0 |
0.55+0/-0.001 |
Typical=0.12 max≤0.35 |
|
|
SM Standard MT Ferrule |
0.125+0.0013/-0 |
0.55+0/-0.001 |
Typical=0.25 max≤0.7 |
|
|
SM Low Loss MT Ferrule |
0.125+0.0009/-0 |
0.5490+0.0006/-0 |
Typical=0.12 max≤0.35 |
|
|
MT-36 |
MM Standard MT Ferrule |
0.125+0.002/-0 |
0.7±0.001 |
Typical=0.25 max≤0.5 |
|
MT-24-Mini |
MM Standard MT Ferrule |
0.125+0.002/-0 |
0.7±0.001 |
Typical=0.25 max≤0.5 |
|
MM Low Loss MT Ferrule |
0.125+0.002/-0 |
0.7+0/-0.001 |
Typical=0.12 max≤0.35 |
MT Ferrules in MPO Connector
MT ferrule plays an important role in the connection as a key component in MPO ferrule connectors. By mating with another MT ferrule, the final quality of connection decides the optical performances insertion loss and return loss.
As an important element, MT Ferrule is generally applied in high-density fiber networks. Except for MTP/MPO ferrule, it is also assembled with MT/Fiber Array as devices used in modules and optical transceivers.
MT Ferrule Applications
FTTx hardened connector cabling infrastructure
MPO cable assemblies
Optical backplane connectivity for OBO architectures
If you need any kinds of fiber optic products, please contact us, as a professional fiber optic products supplier, T&S is willing to offer you high quality products.
