Optical fiber static laser marking machine

1. Model introduction
Pneumatic marking machine uses high-frequency micro punching technology and microcomputer control technology. It can print all kinds of Chinese and English characters, Arabic numerals and any graphics on the plane. The whole machine adopts three-axis synchronous control. If rotating tooling is used, it can mark the circumference of the product; The drive system adopts fully sealed structure; Suitable for all kinds of
Different working environment; It provides a reliable guarantee for the long-time operation of the machine. It is an ideal equipment for automatic production of red marking.
2. Technical parameters
Print content: Chinese and English characters, numbers, serial numbers, various patterns
Character size: 140 adjustable within the printing range × 80mm (can be customized according to user requirements)
Printing depth: 0.02 ~ 1mm (adjustable, related to material)
Printing speed: 3 ~ 6 characters / S
Printing materials: Metallic and non-metallic materials with hardness below HRC60 degrees
Power supply: AC220V ± 10% 50Hz
Air source pressure: 0.2 ~ 0.7MPa
Gas consumption: 3L / S
Power consumption: 300W
Repetition accuracy: 0.02 ~ 0.05mm
Overall weight: 7kg (rq17-e)
3. Model characteristics
The pneumatic marking machine is applicable to the marking of large, heavy and difficult to handle workpiece plane or curved surface with concave convex height no more than 2mm. Such as chassis and frame of engine, diesel engine and electric vehicle; Marks of oil tank truck, semi-trailer, large valve, etc.
