What is the WIFI application?

Wireless network wireless Internet access is more commonly used in big cities. Although the wireless communication quality transmitted by Wi-Fi technology is not very good, the data security performance is worse than Bluetooth, and the transmission quality needs to be improved, but the transmission speed is very fast, which can reach 54Mbps.

Product Features:

1. Dual mode, full compatible with ITU-T G.984 or IEEE 802.3ah

2. Support Web for local management

3. Support Auto-negotiation and MDI/MDIX

4. Support the Ethernet interface rate, working mode and flows control

5. Support loopback at UNI

6. Support packet filtering and anti-illegal message attack protection

7. Support performance statistics of Ethernet lines

8. Support VLAN tagged label processing, traffic classification etc.

9. Support DHCP Option60 reporting the location information of the Ethernet interface

Hardware Parameter:

1. PON Port: 1 G/EPON Optical Interface; Single Fiber: 1*SC/UPC Fiber

2. Upstream Rate: GPON: 1.244Gbps EPON: 1.25Gbps

3. Downstream Rate: GPON: 2.488Gbps EPON: 1.25Gbps

4. Type: BOSA

5. Wavelength: Tx 1310nm, Rx 1490nm

6. Optical Output Power: GPON: +0.5~+5dBm EPON: -1~+4dBm

7. Sensitivity: GPON: -28dBm EPON: -26dBm

8. Overload: GPON: -8dBm EPON: -3dBm

9. LAN: 1*10/100/1000Mbps and 1*10/100Mbps; Full / Half-Duplex, RJ45, Auto-MDI/MDI-X.

Main Functions:

1. GPON Feature 1: Compliant with ITU-T G.984 GPON standard

2. GPON Feature 2: FEC (Forward Error Correction) in both upstream and downstream Dynamic bandwidth status report

3. GPON Feature 3: 802.1p mapper for upstream

4. GPON Feature 4: QoS scheduling based on SP or WRR between GEM port and T- CONT

5. GPON Feature 5: Downstream multicast GEM port and broadcast GEM port

6. EPON Feature 1: IEEE 802.3ah EPON standard

7. EPON Feature 2: EPON interworking standard of China Telecom and China Unicom 20Km transmission distance on single fiber

8. EPON Feature 3: 128Bits uplink and downlink triple-churning Standard OAM and Extension OAM management ONU software batch upgrading

9. EPON Feature 4: PON port support optical power detection

10. Gateway Feature 1: WAN support Router and Bridge mode Router mode supports PPPoE/DHCP/ static IP WAN support Internet, IPTV, TR069

VOIP Feature:

1. Call Protocol: SIP, seamless compatible with all popular call agent

2. Voice Coding: ITU-T G.711/G.723.1(5.3K/6.3Kbit/s)/G.729, auto-negotiate with call agent

3. IP Address Assignment: Dynamic PPPoE/DHCP Client and static IP

4. Call Loss: Less than 0.01%

5. Function-1: Integrate heartbeat function and support active/standby call agent

6. Function-2: Echo cancellation exceeding ITU-T G.165/G.168-2002, up to 128ms tail length

7. Function-3: Support high/low speed fax, bypass fax, and T38 fax

8. Function-4: Support RFC2833 and redundant RFC2833, difference rings, MD5

9. Function-5: authentication, call forward, call waiting, hot-line call, alarm clock, and all kinds of value-added voice service

10. Function-6: Multi-party conferencing.
