1GE 1FE CATV FXS USB WIFI ONU

FTTB disadvantages:Fttx Fttb Application as a high-speed networking advantage is obvious,but the shortcomings should also be seen that ISP must invest a large amount of funds to lay high-speed networks to each user home,so greatly limit the promotion and application of FTTB,to truly let Most netizens must have a lot of work.

Product interface:Interface:hardware interface,looking at the interface direction from left to right,the interface sequence is:RJ11 Telephone Port,network port 2-network port 1(where network port 2 is the iTV interface),wireless switch,reset button,USB interface,DC 12 volt interface,power switch.

Indicator light:LED definition from left to right: power supply,optical fiber G,optical signal,broadband,Telephone Port,network port 1-2,USB

Iron Casing Onu Product feature：

1.Industrial Grade ONU product form, supports bridging and NAT modes；

2.BOB product technology;
3.802.11 b/g/n wireless access;
4.Wireless Device use 2T2R built-in dual antenna;
5.Provide a Voip/fxs Port interface to support connection to ordinary telephones;

6.The USB interface supports configuration saving and restoration;

7.12V/1A external power supply;

Processor features

>Support ARM processor with 800MHz frequency;

>Support 32KB I-Cache and D-Cache;

1*PON port1*10/100/1000M Ethernet Port

1*10/100M Ethernet Port
1*POTS voice port
1*way 2.4G WIFI interface
1*CATV interface

Other features:

Certification:Comply with CE,FCC,ROHS and other standards
EMC/EMI:Comply with VCCI Class B,FCC Part 15 B standards
Safety:Comply with UL 60950 safety regulations
Anti-lightning and anti-surge voltage protection:in line with ITU-T K.21 standard

Project Using Onu Physical characteristics:

Physical size:210*135*33mm

Power supply:12V/1A

Power consumption:8W

Temperature:

Working temperature:-10～55℃

Storage temperature:-30～60℃

Relative humidity:10～90% (non-condensing)

Products details:
