Duratron® D7015G 15% Graphite-filled PI

Duratron® D7015G PI Polyimide is a bearing grade PI that exhibits superior temperature and wear resistance qualities, while offering a low coefficient of friction. Not only does hot compression molded Duratron® D7015G PI maintain its performance abilities with or without lubrication, but with 15% graphite added to provide long wear and low friction, it is a great choice for bearing, bushing, and seal applications where higher loads or speeds are a significant factor.

Material Properties

Superior temperature and wear resistance

Low coefficient of friction

No lubrication needed

Suitable for high loads and speeds

Available Geometries

Duratron® D7015G PI stock shapes encompass a range of standard sizes in the following geometries: Plate

Plate

Available Colors

Duratron® D7015G PI stock shapes come in the following colors: Dark Grey

Applications

High Pressure High Temperature Bushings and Bearings

Valve and pump seats, seals and wear surfaces

Metal replacement for Aerospace components - lightweight, lubrication free

Key Properties

THERMAL RESISTANCE OVER 500°F

Good chemical resistance

Easily machined from a broad range of shapes - rod, sheet, tubular forms

High strength, tough and dimensionally stable

Lower K Wear Factor than Duratron D7000

Higher Limiting PV than Duratron D7000

Limitations

Chemical Resistance to Some Strong Acids and Bases

Hydrolyzes in Presence of Steam
