Green Oilon Sheet thickness 6mm to 50mm

Oilon was the very first authentic lubricated Nylon having a blended liquid lubricant system built in during the process stages, which obviously resulted in a substantial increase in bearing life 5 times that of Natural cast nylon and 25 times that of phosphor bronze. The lubricant contained within the material will not drain, machine, spin, leech or dry out and never needs replenishment.A uniformed distribution of the lubricant throughout the product guarantees a constant performance over the whole service life and improvements in rate of wear, sliding frictional properties abrasion resistance and stick slip performance are just a few of the benefits offered by this material.Oilon was specially developed to extend the wear resistant properties of unlubricated or dry lubricated materials such as MoS2 filled nylons.Nylon 6 Nylon 66

Oilon Sheet and block is definitely a substantial upgrade in terms of performance over Nylon 6 natural and even the black grade. Although Oilon Sheet is actually Nylon 6 its real magic is in the special additive the manufacturers mix in right at the start. Oilon has a special industrial grade oil lubricant mixed in at the very beginning of the manufacturing process which ensures that the sheet has a perfectly even blend throughout the whole structure of the sheet.Cast Nylon Round Bar

Mc Nylon Plate Colour:

One of the first and most obvious features of Oilon Sheet is the green colour, as we have said before, the shade of the green will vary per batch, Oilon Sheet is more recently coming in as similar to British Racing Green.

Highly Rated:

In all the instances where our customers have performed some sort of trial or analysis in real life service of Oilon Sheet, it has lived up to its reputation every time. We have customers who have put Oilon Sheet through some pretty harsh and abrasive environments and its convinced them to swap from normal Nylon Sheet to Oilon Sheet. We are also told that Oilon Sheet seems to make slide blocks much quieter in operation, something that came as a bonus and captured as a selling feature.

Pa6G Sheet Rod Easy To Machine:

Because Oilon Sheet is in essence Nylon 6 Cast, it will machine in just the same way as regular Cast Nylon although the extra lubricant should provide some advantages there. Oilon Sheet is also manufactured using the cast process which inherently provides an engineering plastic with lower stress levels. It is also put through a rigorous annealing process to reduce internal stress to a minimum which means that machined components will stay pretty stable once they have finished the machining process.

Pa6,Pa66 Application:

Typical Industrial Users:

Petrochemical

Aerospace

Railways

Ship Building

Food and Food Packaging , Bottling and Canning

Pharmaceutical

Steel Mills

Quarrying / Mining

Cranes Shoe Manufacturing

Conveyors

Typical Applications:

Rollers

Bushes

Gears

Guides Sheaves

Thrust Washers

Pulleys Chain Guide

Cutting Boards

Wear Strip Starwheels

Scrolls

Clamps

Spacers Liners

Ploughs

Mandrels

Sprockets Cams

Seals

For high-pressure thin walled bearings and

For highly loaded rudder bearing applications where there is a risk of adhesive wear.

In the food industry in non-food contact areas where no grease is permitted.

Features:

OILON is a very unique grade and is becoming increasingly popular. Its characteristics are :

First authentic lubricated nylon (Self-lubricating)

High strength polymer

Enhanced wear and abrasion resistance (upto 5x as compared to Cast Nylon)

Improved coefficient of friction and stick/slip characteristics

Best dry running capability

Improved PV characteristics

Consistent wear performance throughout product life

Reduced water absorption

Excellent mechanical, thermal and chemical resistance properties

FDA compliant for direct food contact application (Ertalyte grade)

Good dimensional stability

Blended liquid lubricant system

AVAILABLE COLOURS :- Green

STANDARD SIZE :- 1 mtr x 1 mtr

STANDARD THICKNESS :- 6 mm to 50 mm
