5.5 Inch LCD TFT Display

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

5.5 Inch LCD TFT Display

A liquid crystal display (LCD) is a type of display which uses the light modulating (polarizing) properties of liquid crystals. They are semi-solid crystals arranged on a substrate. Liquid crystals do not emit light directly, they are the medium that helps the light to bend/rotate. An LCD screen consist of a large number of small pixels, each having a combination of red, green and blue sub-pixels. LCD uses the property of persistance of vision of Human eye due to which we see the video.

ITEM	Sandard value	Unit
LCD Type	Normally black	--
Drive element	TFT active matrix	--
Number of pixels	720*3RGB(H)X1280(V)	Dots
Pixel arrangement	RGB stripe	--
pixel size	94.5 x 94.5	um
Active area	67.93(W) × 120.77(H)	mm
Viewing direction	ALL O’CLOCK	-
TFT Driver IC	NV3051D-T
TFT interface	MIPI Interface	-
Approx. Weight	TBD	g
Module Size(WHT)	71.30(W) ×128.8(H) ×1.66(T)	mm
LCM+CTP Size(WHT)	74.30(W) ×138.70(H) ×2.97(T)	mm
Touch structure	G+FF
Touch Driver IC	GT911	-
Touch Interface	I2C

1.54 Inch Lcd Display Lcd Display Size
