Product Description

The temperature range from -20℃ to +50℃ can be used normally, and the low temperature working temperature of tft-lcd after temperature reinforcement can reach -80 ℃.It can be used as mobile terminal display, desktop terminal display, and large screen projection TV. It is a full-size video display terminal with excellent performance.
It is mainly used in computers, video terminals, communication and instrumentation, desktop computer monitors, workstations, industrial monitors, global positioning system (GPS), personal data processing, game consoles, video phones, portable VCD, DVD and other portable devices.

Model: 395005S0-CTP
Resolution: 480*480
Viewing angle: IPS
Display color: 16.7M
Product structure: LCD+CTP
Product features: high brightness, full viewing angle, square display, touch integration.
Application fields: smart home, 86 box panel, smart switch panel, advertising player, medical equipment, serial port display module, automotive electronics, industrial control equipment, Internet of Things, household appliances, etc.

ITEM	Sandard value	Unit
Model Number	395005S0-CTP
size	3.95	Inch
LCD Type	Normally Black	--
Drive element	TFT active matrix	--
Number of pixels	480*3RGB(H)X480(V)	Dots
Pixel arrangement	RGB stripe	--
Pixel Pitch (W*H)	0.1497*0.1462	mm
Active area	71.856(H) * 70.176(V)	mm
CTP+LCM Mechanical Outline Size(WHT)	84.484.43.6	mm
LCM Mechanical Outline Size(WHT)	74.8377.682.15	mm
CTP Mechanical Outline Size(WHT)	84.484.41.28	mm
Viewing direction	ALL O’CLOCK	-
LCM Driver IC	ST7701S	-
LCM interface	RGB 18 BIT Interface	-
Lcm pin n count	40
Touch screen structure	G+G
Touch Driver IC	GT911	-
Touch Interface	I2C
Backlight leds	8	pcs
Backlight current	40	ma
Backligh voltage	12	v
operating temperature	-20+70	℃
storage temperature	-30+80	℃
Lumens degrees	300	Cd/㎡
