500lb Stainless Steel Single Point Load Cell

Single Point Load Cell, which comply with the range of 0.1kg-2T, the applicant for all kinds of electronic scales, packaging scales, and automatic weighing devices.

Most of Hanyu's Load Cells are the OIML load cell, ROHS load cell. from Small Load Cells to big load cells, with aluminum alloy material, surface anodized treatment, excellent anti-corrosion performance, can be used in various harsh environments.

For HTQ-E-A, the rated capacity is 50, 100, 200, 250, 500lb. Mainly used for price computing scales, counting scales, packing machinerys etc.

Key Features

* Stainless steel
* With humidity resistant protective coating
* Output adjustment for parallel using.
* Max platform size: 400 x 400mm

Applications

Mainly used for price computing scales, counting scales, packing machinerys etc.

Dimensions

Specifications

Model No.:	HTQ-E-A
Rated Capacity	50, 100, 200, 250, 500lb
Accuracy Class	B
Rated output	2.0±0.25%mV/V
Zero balance	±2%R.O.
Input resistance	385±10Ω
Output resistance	350±3Ω
Linearity Error	±0.02%R.O.
Repeatability Error	±0.015%R.O.
Hysteresis Error	±0.015%R.O.

Creep in 30 minute	±0.03%R.O.
Temp.Effect on Output	±0.03%R.O./10°C
Temp.Effect on Zero	±0.03%R.O./10°C
Compensated Temp.Range	-10 - +40°C
Excitation, Recommended	5 - 12VDC
Excitation, Maximum	18VDC
Operating Temperature Range	-20 - +60°C
Safe overload	150%.R.C.
Ultimate overload	200%.R.C.
Insulation Resistance	≥2000MΩ(50VDC)
Cable,and length	φ6mm × 3m
Protection Class	IP66
