NH6T5 500kg Shear Beam Torque Load Cell
-
$16.00≥800 Piece/Pieces
- Min. Order:
- 800 Piece/Pieces
- Min. Order:
- 800 Piece/Pieces
- Transportation:
- Ocean, Land, Air, express
- Port:
- Shenzhen China
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen China |
|---|---|
| Productivity: | 100000 Piece per Month |
| Supply Ability: | 100000 Piece per Month |
| Payment Type: | L/C,T/T,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,EXW |
| Certificate: | ISO9001. ISO14001 |
| HS Code: | 9026809000 |
| Transportation: | Ocean,Land,Air,express |
| Port: | Shenzhen China |
Product Description
Product Description
A shear force sensor is a sensor used to measure the shear force applied to an object. It usually consists of an elastic element and a sensitive element.
|
|
Wiring method: |
|
|
Technical parameter table
| PARAMETERS | |||
| Sensor Range | KG | 5-500 | Rated load |
| Accuracy level | C3 | ||
| Comprehensive error | FS | ±0.03% & ±0.02% | Comprehensive error |
| sensitivity | mv/v | 2.0±0.2 | Rated output |
| Zero point output | FS | ±1% | Zero balance |
| creep | %FS/30min | 0.03 | Creep |
| Zero temperature effect | %FS/10℃ | 0.02 | Temp.effect on zero |
| Sensitivity temperature influence | %FS/10℃ | 0.03 | Temp.effect on span |
| Input impedance | Ω | 350±5 | Input resistance |
| Output impedance | Ω | 405±10 | output resistance |
| insulation resistance | MΩ | ≥5000(100V) | Insulation resistance |
| Temperature compensation range | ℃ | -10-40 | Compensated temp.range |
| Operating temperature range | ℃ | -35-65 | Use temp.range |
| Excitation voltage | V | 5-12（DC） | Excitation voltage |
| Safe overload range | % | 150 | Safe overload |
| Protection level | IP68 | Defend grade | |
| wire | m | 1.5米Φ5屏蔽线 | Cable |
Overall dimensions:
|
