Long Life Service Oxygen Generator Psa

Introduction:

Pressure Swing Adsorption (Pressure Swing Adsorption. PSA for short) is a new type of gas adsorption separation technology. It has the following advantages: the product is of high purity; it can generally work at room temperature and low pressure, and it does not need to be heated when the bed is regenerated. High purity; simple equipment, easy operation and maintenance; continuous cycle operation can be fully automated.

Details of PSA Oxygen Generator /Gas Cylinder

Oxygen Capacity： 1 ~ 1000Nm3/h

Oxygen purity： 93%±3%

Oxygen Pressure： ≤3 bar(Adjustable)

Oxygen Dew point： ≤-40ºC(Adjustable)

Oxygen Generator Flow Chart:

The working process of the PSA Oxygen Generation Plant is to compress the air through the air compressor, then dedust, degrease, dry, and put it into the air storage tank. At this time, the gas entering the air storage tank enters the left adsorption tower through the left inlet valve, the nitrogen molecules in the gas are adsorbed by the zeolite molecular sieve, and the oxygen is released and enters the oxygen storage tank through the left gas production valve and the oxygen gas production valve; this The process is called left suction and lasts for tens of seconds.
