High Purity Oxygen Plant Medical Oxygen Generator
Oxygen production:5 ~ 200Nm3/h
Purity of oxygen:90% ~ 95%
Oxygen pressure:0.1 ~ 0.4MPa(Adjustable)
Dew point:-40ºC or -60ºC
Oxygen Production Equipment and Nitrogen Production Equipment are selling hot. We also have SMT cleaning machine, SMT nozzle and SMT feeder for sale. please contact us if you need.
The main products of ROC: SMT Cleaning Machine, PSA oxygen / nitrogen generator, wafer cleaning equipment, PCBA Cleaning Machine, SMT Spare Parts, SMT Nozzle, SMT Feeder etc. If there is any need, please contact us.
1. Equipment Installation Condition
|
Item |
Description |
Remark |
||
|
Power |
220V/50Hz |
100W |
Power for Oxygen Generator |
|
|
220V/50Hz |
60W |
Power for Heatless Air Dryer |
||
|
Environment Temperature |
≤38℃(good ventilation) |
/ |
||
|
Gas(PSA gas consumption)
|
Capacity |
≥ 0.77Nm3/min (20℃,101.325kPa) |
Air Compressor Output Requirements |
|
|
Pressure |
≥ 0.7MPa |
|||
|
Temperature |
≤ 50 ℃ |
|||
|
Oil Content |
≤ 3 PPm |
|||
|
Dust Size |
≤ 5 μm |
|||
2. Oxygen Generator Specification
| oxygen capacity | 2-200Nm3/h |
| oxygen purity | 93%+-2% |
| output pressure | 0.1-0.5MPa(1-5Bar) adjustable / 15MPa filling pressure offered |
| Specification | output (Nm³/h) | Effective gas consumption (Nm³/h) | air cleaning system |
| CBO-5 | 5 | 0.95 | KJ-1 |
| CBO-10 | 10 | 2.1 | KJ-2 |
| CBO-20 | 20 | 4.0 | KJ-6 |
| CBO-40 | 40 | 8.2 | KJ-10 |
| CBO-60 | 60 | 12.3 | KJ-12 |
| CBO-80 | 80 | 16.3 | KJ-20 |
| CBO-100 | 100 | 20.8 | KJ-20 |
| CBO-150 | 150 | 30.7 | KJ-30 |
| CBO-200 | 200 | 41 |
KJ-40 |
3. Process Flow Brief Description
4.Technical Features
1).Full Automation
All systems are designed for un-attended operation and automatic Nitrogen demand adjustment.
2).Lower Space Requirement
The design and Instrument makes the plant size very compact,assembly on skids,prefabricated from factory.
3).Fast Start-up
Start-up time is only 5 minutes to get desired Nitrogen purity.So these units can be switched ON&OFF as per Nitrogen demand changes.
4).High Reliabiity
Very reliable for continuous and steady operation with constant Nitrogen purity.Plant availability time is better than 99% always.
5).Molecular Sieves life
Expected Molecular sieves life is around 15-years i.e. whole life time of nitrogen plant.So no replacement costs.
6).Adjustable
By altering flow,you can deliver nitrogen with precisely the right purity.
Send Inquiry Please bring the following description, we have more models to recommend to you ~! Thank you~!
| Technical Information | Your Kind Requirement |
| Capacity |
_________Nm³/h |
| Purity | _________% |
| Outlet Pressure | _________Mpa or Bar |
| Power |
________V/HZ |
