On-site Nitrogen Generator for Injection Molding Industry

On-site Nitrogen Generator for Injection Molding Industry

For most capacities, 99.999% purity Psa Nitrogen Generator, one-time production, no need for secondary purification

On-site Nitrogen Generator for Injection Molding Industry

During the injection molding process, the purity of the nitrogen gas should be 99.99% or above. At the same time, the pressure varies from manufacturer to manufacturer, and generally requires a pressure of 1.5Mpa or more. If you use bottled nitrogen, you need to change the air frequently, and the operation is still more troublesome, so it is recommended to use an on-site nitrogen generation system. As long as pure compressed air enters the nitrogen production system, high-purity nitrogen can be obtained, and then connected to the nitrogen pressurization system, the nitrogen can be increased to the required pressure.

Under the condition that the parts can meet the same use requirements, the use of gas-assisted injection molding can greatly save plastic raw materials, and the saving rate can be as high as 20-40%. On the one hand, the reduction in the amount of plastic raw materials leads to a reduction in the time of each link of the entire molding cycle; on the other hand, the shrinkage and deformation of the parts have been greatly improved through the introduction of high-pressure gas inside the parts, so there is a nitrogen generator The injection pressure holding effect in air-spreading injection molding.

Service:

1.reasonable activated carbon modular design, convenient and quicker to replace dispense with professional
personnel.
2.Can provide purties９９.９９９％Nitrogen gas at a time ,  purity stability,  pressure stability
3.Using Siemens HMI,display the parameters , such as the nitrogen purity and real-time nitrogen flow, more humane.
4.A key boot,automatic oxygen supply after the N2 purity qualified
5.Adopt imported BURKERT valve, long service life, stable property
6.Adopt imported SMC meter, measuring gas flow accurately, stable performance

Related Products： SMT Cleaning Machine, PSA oxygen / nitrogen generator, SMT Spare Parts etc. If any need, please contact us.、

Nitrogen capacity: 1- 2000Nm3/h

Nitrogen purity: 95%-99.999%
Nitrogen pressure: 0.5-0.8Mpa( boost for high pressure
Nitrogen dew point: s-40.C(Atmosphere pressure)
Customized pressure, purity and capacity ranges.

Technical characteristics
1.The material source is from the nature, the system only needs compressed air and power, so the cost of power and operation is less
2. Nitrogen purity is easy to adjust, it is only affected by the capacity, purity of normal nitrogen is at the range of 95%-99.99%(can be adjusted), purity of high nitrogen is at the range of 99%-99.999%(can be adjusted)
3. The system is automatic, quick starting and no need to monitor. One button for start and stop, run 10-15 minutes to generate the N2 air
4. The working progress is easy, the configuration is compact, the landing space is less and the environment is well-adapted
5. Snow storm filling can avoid the damage of CMs
6. Digital flow meter has pressure compensation, it is highly precise meter which can monitor the progress, it can test quick flow and accumulate the total capacity
