Maintex 20BYJ professional micro motor stepper
Your message must be between 20 to 2000 characters
Contact NowChina maintex with FUji 20byj46 7.5degree stepper motor
Specification:
Diameter: 20 mm
Step Angle: 7.5 degree
Voltage: 5V, can be customized.
Phase: 4
Rotation: CW/CCW
Excitation: Bipolar, 1-2
Parameter of China maintex with FUji 20byj46 7.5degree 1/85 micro stepper motor
| Items | Spec. |
| Step Angle(degrees) | 7.5degree |
| Holding Torque | 80mN.m |
| Reduction Ratio | 1/85 |
| Detent torque | ≥60mN.m |
| No-load Pull-out torque | ≥800mN.m |
| Current / Phase | 20 ohm±10% |
| Height of output shaft | 10.2±0.5mm |
| Input Torque | ≥90mN.m(DC5V,400HZ) |
| OEM | Accept |
Drawing of China maintex with FUji 20byj46 7.5degree 1/85 micro stepper motor
Application of China maintex with FUji 20byj46 7.5degree 1/85 micro stepper motor
Our Company Maintex&FM
