TM050RDHG16 5.0 Inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | Paypal,T/T |
| Incoterm: | FOB,EXW |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
TM050RDHG16 is a 5.0 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, without backlight driver, without touch screen. This Tianma TFT-LCD is a 5.0 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. TM050RDHG16 supports display 800(RGB)×480 (WVGA), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 108(W)×64.8(H) mm, outline size of 120.7(W)×75.8(H)×3.1(D) mm, viewing area size of 111.1(W)×67.9(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 62.0g (Typ.). As a TN, Normally White, Transmissive LCM product, TM050RDHG16 can provides 250 cd/m² display brightness 600:1 transimissive contrast ratio, 70/70/50/70 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12 o'clock , and response time of 20 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Dithering gray scale signal for each dot, thus presenting a palette of 16.2M colors, also with performance of color gamut 70% (NTSC). This product adopted 7S2P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. TM050RDHG16 utilizes Parallel RGB (1 ch, 8-bit) as it's signal inputting systerm, which connected by 40 pins FPC with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
TM050RDHG16 |
|
Brand |
TIANMA |
|
Diagonal Size |
5.0" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
800(RGB)×480, WVGA 188PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
108(W)×64.8(H) mm |
|
Bezel Opening |
111.1(W)×67.9(H) mm |
|
Outline Dim. |
120.7(H)×75.8(V) ×3.1(D) mm |
|
Treatment |
Antiglare, Hard coating (3H) |
|
Luminance |
250 cd/m² (Typ.) |
|
Contrast Ratio |
600:1 (Typ.) (TM) |
|
View Direction |
12 o'clock |
|
Response Time |
20 (Typ.)(Tr+Td) |
|
Viewing Angle |
70/70/50/70 (Typ.)(CR≥10) |
|
Operating Mode |
TN, Normally White, Transmissive |
|
Support Color |
16.2M 70% NTSC |
|
Light Source |
WLED [7S2P] , 20K hours , W/O Driver |
|
Weight |
62.0g (Typ.) |
|
Frame Rate |
60Hz |
|
Touch Panel |
Without |
|
Interface Type |
Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
|
Power Supply |
3.3V (Typ.) |
|
Environment |
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Product Picture:
