TM040YDHG41 4.0 Inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | Paypal,T/T |
| Incoterm: | FOB,EXW |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
TM040YDHG41 is a 4.0 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, without backlight driver, without touch screen. This Tianma TFT-LCD is a 4.0 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. TM040YDHG41 supports display 480(RGB)×800 (WVGA) with aspect ratio of 3:5 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 51.84(W)×86.4(H) mm, outline size of 57.14(W)×96.85(H) mm, net weight of 232g (Typ.). As a SFT, Normally Black, Transmissive LCM product, TM040YDHG41 can provides 600 cd/m² display brightness 800:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 15/15 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted 8S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, external backlight driver is additionally needed. TM040YDHG41 utilizes MIPI (2 data lanes) as it's signal inputting systerm, which connected by 25 pins FPC with power supply voltage of 1.8/2.8/3.3V (Typ.)(IOVCC/VDD/VDD). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
TM040YDHG41 |
|
Brand |
TIANMA |
|
Diagonal Size |
4.0" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
480(RGB)×800, WVGA 235PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
51.84(W)×86.4(H) mm |
|
Outline Dim. |
57.14(W)×96.85(H) mm |
|
Luminance |
600 cd/m² (Typ.) |
|
Contrast Ratio |
800:1 (Typ.) (TM) |
|
View Direction |
Symmetry |
|
Response Time |
15/15 (Typ.)(Tr/Td) |
|
Viewing Angle |
80/80/80/80 (Typ.)(CR≥10) |
|
Operating Mode |
SFT, Normally Black, Transmissive |
|
Support Color |
16.7M 72% NTSC |
|
Light Source |
WLED [8S1P] , 50K hours , W/O Driver |
|
Weight |
232g (Typ.) |
|
Frame Rate |
60Hz |
|
Touch Panel |
Without |
|
Interface Type |
MIPI (2 data lanes) , 25 pins FPC |
|
Power Supply |
1.8/2.8/3.3V (Typ.)(IOVCC/VDD/VDD) |
|
Environment |
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Product Picture:
