TM035KBH11-09 3.5 Inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 100000 pcs |
| Payment Type: | T/T,Paypal |
| Incoterm: | EXW,FOB |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
Tianma Microelectronics Co., Ltd. (hereafter called TIANMA) TM035KBH11-09 is a 3.5 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, touchscreen 4-wire Resistive Touch. This Tianma TFT-LCD is a 3.5 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. TM035KBH11-09 supports display 320(RGB)×240 (QVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 70.08(W)×52.56(H) mm, outline size of 76.9(W)×63.9(H)×4.2(D) mm, viewing area size of 72.08(W)×54.56(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 40.6g. As a TN, Normally White, Transmissive LCM product, TM035KBH11-09 can provides 350 cd/m² display brightness 400:1 transimissive contrast ratio, 70/70/60/70 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12 o'clock , and response time of 20 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Dithering gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 50% (NTSC). This product adopted 6S1P WLED as it's backlight systerm which was placed as Edge light type, external backlight driver is additionally needed. TM035KBH11-09 utilizes Digital RGB (8/24-bit) + SPI, CCIR601/656 as it's signal inputting systerm, which connected by 54 pins FPC with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
TM035KBH11-09 |
|
Brand |
TIANMA |
|
Diagonal Size |
3.5" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
320(RGB)×240, QVGA 115PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
70.08(W)×52.56(H) mm |
|
Bezel Opening |
72.08(W)×54.56(H) mm |
|
Outline Dim. |
76.9(H)×63.9(V) ×4.2(D) mm |
|
Treatment |
Antiglare, Hard coating (3H) |
|
Luminance |
350 cd/m² (Typ.) |
|
Contrast Ratio |
400:1 (Typ.) (TM) |
|
View Direction |
12 o'clock |
|
Response Time |
20 (Typ.)(Tr+Td) |
|
Viewing Angle |
70/70/60/70 (Typ.)(CR≥10) |
|
Operating Mode |
TN, Normally White, Transmissive |
|
Support Color |
16.7M 50% NTSC |
|
Light Source |
WLED [6S1P] , W/O Driver |
|
Weight |
40.6g |
|
Frame Rate |
60Hz |
|
Touch Panel |
4-wire Resistive Touch |
|
Interface Type |
Digital RGB (8/24-bit) + SPI, CCIR601/656 , 54 pins FPC |
|
Power Supply |
3.3V (Typ.) |
|
Environment |
Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
Product Picture:
