TM104TDGP10 TIANMA 10.4 inch TFT-LCD
- Payment Type:
- T/T, Paypal, Western Union
- Incoterm:
- FOB, EXW
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 3 Days
- Transportation:
- Ocean, Land, Air
- Port:
- HK, Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | TAIWAN |
|---|---|
| Payment Type: | T/T,Paypal,Western Union |
| Incoterm: | FOB,EXW |
| Certificate: | CE,ROHS,ISO9001 |
| Transportation: | Ocean,Land,Air |
| Port: | HK,Shenzhen |
TM104TDGP10 is a 10.4 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, With LED Driver, without touch screen. Tianma TFT-LCD is a 10.4 inch with consumer Lcd Display, it have LCD Controller and Tft Color Screen. On the basis of latest version datasheet Pre Ver1.0 which was released out on 1 14 2019, TM104TDGP10 supports display 1024(RGB)×768 (XGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 210.432(W)×157.824(H) mm, outline size of 230(W)×175.8(H)×9.06(D) mm, viewing area size of 213.43(W)×160.82(H) mm, with surface treament of Antiglare, net weight of TBD. As a SFT, Normally Black, Transmissive LCM product, TM104TDGP10 can provides 400 cd/m² display brightness 1200:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 8-bit gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 50% (NTSC). This product adopted 8S4P WLED as it's backlight systerm which was placed as Edge light type, With LED Driver. TM104TDGP10 utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model |
TM104TDGP10 |
|
Brand |
TIANMA |
|
Diagonal Size |
10.4 inch |
|
Pixel Format |
1024(RGB)×768 [XGA] |
|
Active Area |
210.432(H)×157.824(V) mm |
|
Bezel Area |
213.43(H)×160.82(V) mm |
|
Luminance |
400 cd/m² (Typ.) |
|
View Direction |
Symmetry |
|
Viewing Angle |
80/80/80/80 (Typ.)(CR≥10) |
|
Support Color |
262K/16.7M 50% NTSC |
|
Weight |
TBD |
|
Frame Rate |
60Hz |
|
Type |
a-Si TFT-LCD , LCM |
|
Configuration |
RGB Vertical Stripe |
|
Outline Dim. |
230(H)×175.8(V) ×9.06(D) mm |
|
Treatment |
Antiglare |
|
Contrast Ratio |
1200:1 (Typ.) (TM) |
|
Response Time |
25 (Typ.)(Tr+Td) |
|
Operating Mode |
SFT, Normally Black, Transmissive |
|
Light Source |
WLED [8S4P] , With LED Driver |
|
Touch Panel |
Without |
|
Interface Type |
LVDS (1 ch, 6/8-bit) 20 pins Connector |
|
Power Supply |
3.3V (Typ.) |
|
Environment |
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Product Picture:
