TM043NVHG08 TIANMA 4.3 inch TFT-LCD
- Payment Type:
- T/T, Paypal, Western Union
- Incoterm:
- FOB, EXW
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 3 Days
- Transportation:
- Ocean, Land, Air
- Port:
- HK, Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | TAIWAN |
|---|---|
| Payment Type: | T/T,Paypal,Western Union |
| Incoterm: | FOB,EXW |
| Certificate: | CE,ROHS,ISO9001 |
| Transportation: | Ocean,Land,Air |
| Port: | HK,Shenzhen |
TM043NVHG08 is a 4.3 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, without backlight driver, touch screen PCAP. Tianma TFT-LCD is a 4.3 inch with consumer Lcd Display, it have LCD Controller and Tft Color Screen. On the basis of latest version datasheet Pre Ver1.2 which was released out on 4 25 2016, TM043NVHG08 supports display 480(RGB)×272 (WQVGA) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 95.04(W)×53.856(H) mm, outline size of 113.44(W)×71.46(H)×5(D) mm, viewing area size of 96.04(W)×54.86(H) mm, net weight of TBD. As a TN, Normally White, Transmissive Assembly product, TM043NVHG08 can provides 350 cd/m² display brightness 900:1 transimissive contrast ratio, 80/80/80/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 20 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 50% (NTSC). This product adopted 5S2P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. TM043NVHG08 utilizes Parallel RGB (1 ch, 8-bit) as it's signal inputting systerm, which connected by 40 pins FPC with power supply voltage of 3.3/7.5V (Typ.)(VDD/VPP). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model |
TM043NVHG08 |
|
Brand |
TIANMA |
|
Diagonal Size |
4.3 inch |
|
Type |
a-Si TFT-LCD, Assembly |
|
Pixel Format |
480(RGB)×272 [WQVGA] |
|
Configuration |
RGB Vertical Stripe |
|
Active Area |
95.04(H)×53.856(V) mm |
|
Outline Dim. |
113.44(H)×71.46(V) ×5(D) mm |
|
Bezel Area |
96.04(H)×54.86(V) mm |
|
Luminance |
350 cd/m² (Typ.) |
|
Contrast Ratio |
900:1 (Typ.) (TM) |
|
View Direction |
6 o'clock |
|
Response Time |
20 (Typ.)(Tr/Td) |
|
Viewing Angle |
80/80/80/60 (Typ.)(CR≥10) |
|
Operating Mode |
TN, Normally White, Transmissive |
|
Support Color |
16.7M 50% NTSC |
|
Light Source |
WLED [5S2P] , 20K hours , W/O Driver |
|
Weight |
TBD |
|
Frame Rate |
60Hz |
|
Touch Panel |
PCAP |
|
Interface Type |
Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
|
Power Supply |
3.3/7.5V (Typ.)(VDD/VPP) |
|
Environment |
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Product Picture:
