TM043NBHG04 TIANMA 4.3 inch TFT-LCD
- Payment Type:
- T/T, Paypal, Western Union
- Incoterm:
- FOB, EXW
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Delivery Time:
- 3 Days
- Transportation:
- Ocean, Land, Air
- Port:
- HK, Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | TAIWAN |
|---|---|
| Payment Type: | T/T,Paypal,Western Union |
| Incoterm: | FOB,EXW |
| Certificate: | CE,ROHS,ISO9001 |
| Transportation: | Ocean,Land,Air |
| Port: | HK,Shenzhen |
TM043NBHG04 is a 4.3 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, touchscreen 4-wire Resistive Touch. Tianma TFT-LCD is a 4.3 inch with consumer Lcd Display, it have LCD Controller and Tft Color Screen. TM043NBHG04 supports display 480(RGB)×272 (WQVGA) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 95.04(W)×53.856(H) mm, outline size of 105.5(W)×67.2(H)×4.4(D) mm, with surface treament of Hard coating (3H), net weight of 59.4g (Typ.). As a TN, Normally White, Transmissive LCM product, TM043NBHG04 can provides 800 cd/m² display brightness 800:1 transimissive contrast ratio, 70/70/70/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 50% (NTSC). This product adopted 8S2P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 20K hours, external backlight driver is additionally needed. TM043NBHG04 utilizes Parallel RGB (1 ch, 8-bit) as it's signal inputting systerm, which connected by 40pins FPC with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
Model
TM043NBHG04
Brand
TIANMA
Diagonal Size
4.3 inch
Pixel Format
480(RGB)×272 [WQVGA]
Active Area
95.04(H)×53.856(V) mm
Luminance
800 cd/m² (Typ.)
View Direction
6 o'clock
Viewing Angle
70/70/70/60 (Typ.)(CR≥10)
Support Color
16.7M 50% NTSC
Weight
59.4g (Typ.)
Frame Rate
60Hz
Type
a-Si TFT-LCD , LCM
Configuration
RGB Vertical Stripe
Outline Dim.
105.5(H)×67.2(V) ×4.4(D) mm
Treatment
Hard coating (3H)
Contrast Ratio
800:1 (Typ.) (TM)
Response Time
25 (Typ.)(Tr+Td)
Operating Mode
TN, Normally White, Transmissive
Light Source
WLED [8S2P] , 20K hours , W/O Driver
Touch Panel
4-wire Resistive Touch
Interface Type
Parallel RGB (1 ch, 8-bit) 40 pins FPC
Power Supply
3.3V (Typ.)
Environment
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
