G150XJE-P01 15.0 inch Innolux TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 1000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | T/T,Paypal |
| Incoterm: | EXW |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
Innolux Corporation (hereafter called Innolux) G150XJE-P01 is a 15.0 inch diagonal a-Si TFT-LCD display screen product, without backlight, With LED Driver, without touch screen. This Innolux TFT-LCD is a 15.0 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. G150XJE-P01 supports display 1024(RGB)×768 (XGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 304.128(W)×228.096(H) mm, outline size of 314.6(W)×237.55(H)×1.3(D) mm, with surface treament of Antiglare, Hard coating (3H), utilizing 0.50+0.50 mm mm plate. As a NPVA, Normally Black, Transmissive CELL product, G150XJE-P01 can provides 2500:1 transimissive contrast ratio, 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 16/7 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 8-bit gray scale signal for each dot, thus presenting a palette of 262K/16.7M colors, also with performance of color gamut 71% (NTSC). This product have no backlight, With LED Driver. G150XJE-P01 utilizes LVDS (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 20 pins Connector with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
G150XJE-P01 |
|
Brand |
Innolux |
|
Diagonal Size |
15.0" |
|
Panel Type |
a-Si TFT-LCD, CELL , FOB |
|
Resolution |
1024(RGB)×768, XGA 85PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
304.128(W)×228.096(H) mm |
|
Outline(mm) |
314.6 × 237.55 × 1.3 (H×V×D) |
|
Treatment |
Antiglare, Hard coating (3H) |
|
Luminance |
0 cd/m² |
|
Contrast Ratio |
2500 : 1 (Typ.) (TM) |
|
Viewing Angle |
88/88/88/88 (Typ.)(CR≥10) |
|
Response |
16/7 (Typ.)(Tr/Td) ms |
|
Good View at |
Symmetry |
|
Work Mode |
NPVA, Normally Black, Transmissive |
|
Glass Thickness |
0.50+0.50 mm |
|
Transmissivity |
4.8% (Typ.)(with Polarizer) |
|
Color Depth |
262K/16.7M 71% NTSC |
|
Backlight |
No B/L , With LED Driver |
|
Refresh Rate |
60Hz |
|
Touchscreen |
Without |
|
Driver IC list |
Built-in 3 source COF + 2 gate COG chips |
|
Signal Type |
LVDS (1 ch, 6/8-bit) , 20 pins Connector |
|
Voltage Supply |
3.3V (Typ.) |
|
Max. Ratings |
Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
Product Picture:
