G070Y2-T02 Innolux 7.0 inch TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|---|
| Productivity: | 1000 PCS |
| Supply Ability: | 10000 PCS |
| Payment Type: | T/T,Paypal |
| Incoterm: | EXW |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
G070Y2-T02 is a 7.0 inch diagonal a-Si TFT-LCD display screen product from Innolux, with a built-in WLED backlight, without backlight driver, without touch screen. This Innolux TFT-LCD is a 7.0 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. G070Y2-T02 supports display 800(RGB)×480 (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 152.4(W)×91.44(H) mm, outline size of 165(W)×104(H)×6.83(D) mm, viewing area size of 154.6(W)×93.64(H) mm, with surface treament of Antiglare, Hard coating (3H), net weight of 132±15g. As a TN, Normally White, Transmissive LCM product, G070Y2-T02 can provides 500 cd/m² display brightness 600:1 transimissive contrast ratio, 70/70/60/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle , and response time of 5/11 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit / 6-bit + FRC gray scale signal for each dot, thus presenting a palette of 262K/16.2M colors, also with performance of color gamut 72% (NTSC). This product adopted 7S2P WLED as it's backlight systerm which was placed as Edge light type (Bottom side) and have a working life time of 50K hours, external backlight driver is additionally needed. G070Y2-T02 utilizes TTL (1 ch, 6/8-bit) as it's signal inputting systerm, which connected by 60 pins FPC with power supply voltage of 3.3/10/19/-6.8V (Typ.)(VCC/AVDD/VGH/VGL). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
G070Y2-T02 |
|
Brand |
Innolux |
|
Diagonal Size |
7.0" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
800(RGB)×480, WVGA 133PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
152.4(W)×91.44(H) mm |
|
Bezel Opening |
154.6(W)×93.64(H) mm |
|
Outline(mm) |
165 × 104 × 6.83 (H×V×D) |
|
Treatment |
Antiglare, Hard coating (3H) |
|
Luminance |
500 cd/m² (Typ.) |
|
Contrast Ratio |
600 : 1 (Typ.) (TM) |
|
Viewing Angle |
70/70/60/60 (Typ.)(CR≥10) |
|
Response |
5/11 (Typ.)(Tr/Td) ms |
|
Work Mode |
TN, Normally White, Transmissive |
|
Color Depth |
262K/16.2M 72% NTSC |
|
Backlight |
7S2P WLED , 50K hours , No Driver |
|
Mass |
132±15g |
|
Refresh Rate |
60Hz |
|
Touchscreen |
Without |
|
Signal Type |
TTL (1 ch, 6/8-bit) , 60 pins FPC |
|
Voltage Supply |
3.3/10/19/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
|
Max. Ratings |
Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
Product Picture:
