AM-800480L1TMQW-TN0H-L AMPIRE 5.0 inch TFT-LCD
-
$20.00≥1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Transportation:
- Ocean, Land, Air
- Port:
- HK, SHENZHEN
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | TAIWAN |
|---|---|
| Payment Type: | T/T,Paypal |
| Incoterm: | FOB,EXW |
| Certificate: | CE,ROHS,ISO9001 |
| Transportation: | Ocean,Land,Air |
| Port: | HK,SHENZHEN |
AM-800480L1TMQW-TN0H-L is a 5.0 inch diagonal a-Si TFT-LCD display screen product from AMPIRE, with a built-in WLED backlight, without backlight driver, touch screen PCAP. This Ampire TFT-LCD is a 5.0 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. On the basis of latest version datasheet 20140630 which was released out on 6 30 2014, AM-800480L1TMQW-TN0H-L supports display 800(RGB)×480 (WVGA) with aspect ratio of 15:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 108(W)×64.8(H) mm, outline size of 118.5(W)×77.1(H)×6.66(D) mm, viewing area size of 110.6(W)×67.4(H) mm, with surface treament of Antiglare. As a TN, Normally White, Transmissive LCM product, AM-800480L1TMQW-TN0H-L can provides 315 cd/m² display brightness 250:1 transimissive contrast ratio, 70/70/70/50 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 15/35 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 52% (NTSC). This product adopted 3S6P WLED as it's backlight systerm which was placed as Edge light type, external backlight driver is additionally needed. AM-800480L1TMQW-TN0H-L utilizes Parallel RGB (1 ch, 8-bit) as it's signal inputting systerm, which connected by 45 pins FPC with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Panel Model |
AM-800480L1TMQW-TN0H-L |
|
Panel Brand |
AMPIRE |
|
Panel Size |
5.0" |
|
Resolution |
800(RGB)×480, WVGA, 188PPI |
|
Display Area |
108(W)×64.8(H) mm |
|
Outline Size |
118.5(W)×77.1(H) ×6.66(D) mm |
|
Brightness |
315 cd/m² (Typ.) |
|
Viewing Angle |
70/70/70/50 (Typ.)(CR≥10) |
|
Best View on |
6 o'clock |
|
Display Colors |
16.7M 52% NTSC |
|
Frequency |
60Hz |
|
Panel Type |
a-Si TFT-LCD , LCM |
|
Pixel Format |
RGB Vertical Stripe |
|
Bezel Opening |
110.6(W)×67.4(H) mm |
|
Surface |
Antiglare |
|
Contrast Ratio |
250:1 (Typ.) (TM) |
|
Display Mode |
TN, Normally White, Transmissive |
|
Response Time |
15/35 (Typ.)(Tr/Td) |
|
Lamp Type |
3S6P WLED , Without Driver |
|
Touch Screen |
PCAP |
|
Signal Interface |
Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
|
Input Voltage |
3.3V (Typ.) |
|
Environment |
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
Product Picture:
