24 Volt 0.5Amp 12W LED Switching Power Supply

24 Volt 0.5Amp 12W LED Switching Power Supply

The switch ac dc adapter is a low cost, accept black or white 12W 24Vdc 500ma desktop style single output nominal ac input 100VAC to 240VAC constant voltage power supplies with standard IEC320-C8 AC Inlet. The dc computer power supply follows the features of US DoE Level VI energy efficiency, low power consumption less than 0.15W and meet latest UL/cUL CE GS KC PSE RoHS FCC CCC safety certifications. The laptop power adapter utilizes the eco-friendly flame retardant plastic housing and provides over current protection, over voltage protection and short circuit protection, 3 years warranty.

Features

◆ Desktop style, up to 12W continuous power

◆ Universal AC input/ Full range

◆ Level VI energy efficiency

◆ Protections: Short circuit / Over voltage / Over current

◆ Class II power (without earth pin): IEC320-C8

◆ Pass LPS (Limited power source)

◆ Compact Size, fully enclosed plastic case

◆ LED indicator for power on

◆ 100% full load burn-in test

◆ 3 years Warranty

Specifications

Dimensions LxWxH (in): 3.228 x 1.575 x 1.181
Dimensions LxWxH (mm): 82 x 40 x 30
Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: Constant voltage mode and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment: -20℃-85%℃ 5%-95%RH
No load power consumption: below 0.21W
Overshoot: 15% Max. When power supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL62368, CSA22.2, TUV EN62368, AS/NZS 62368, GB4943, J62368, K60950

Safety Approvals: UL CUL CE KC GS SAA RCM CB FCC RoHS

Applications: 3D Printer, Ultrasonic Humidifier, LCD Monitor, LED Lights, HDD Enclosure, CCTV, Car DVR, Digital Photo Frame, Mobile Phone, Laptop, Tablet PC, Refrigerators, Portable DVD, Set Top Box, Radio, Security System Products, Massage Products, Electronics Products etc
