High Toughness Black PA6+GF30 Sheet

Get Latest Price

Min. Order:: 100 Kilogram

Min. Order:: 100 Kilogram

Transportation:: Ocean

Port:: Shenzhen Port, Shekou Port

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen,Guangdong(Mainland)
Supply Ability:	2500Ton/Month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF
Certificate:	ROHS,SGS Testing Report
Transportation:	Ocean
Port:	Shenzhen Port,Shekou Port

Product Description

Overview

Quick Details

Place of Origin:Guangdong, China (Mainland)

Brand Name:Anheda

Model Number:Pa6 Sheet

Material:PA6

Thickness:8-100mm

Size:610mm x 1220mm

Product name:Pa6 Gf30 Sheet

Color:Black

Density:1.3g/cm3

Melting point:250 ℃

Bonding capacity:Yes

Food contact:No

Acid resistance:As circumstances

Alkali Resistance:As circumstances

Heat Resistance:110 - 210 ℃

Application:Gears of chemical machinery / Component of domestic applian

Product Description

Nylon Plate, Chinese name polyamide, English name Polyamide (referred to as Nylon 6 Sheet), is a general term for thermoplastic resin containing repeating amide group -NHCO- in the main chain of the molecule.Polyamide sheet is one of the earliest engineering thermoplastics with high tensile strength, impact toughness, good oil resistance, fatigue resistance and self-lub.

Main Ferture

1.Low resistivity,

2.Balanced resistivity,

3.Constant resistivity

4.High mechanical strength,

5.Superior wear resistance

6.Chemical resistance.

Physical Datasheet

Item	Nylon Pa6 Gf30 Sheet
Color	black
Proportion	1.3g/cm³
Heat resistance (continuous)	85℃
Heat resistance (short-term)	160℃
Melting point	220℃
Linear thermal expansion coefficient (average 23~100℃)	90×10-6 m/(m.k)
Average 23--150℃	105×10-6 m/(m.k)
Flammability(UI94)	HB
Tensile modulus of elasticity	3250MPa
Dipping into water at 23℃ for 24h	86%
Dipping into water at 23℃	9%
Bending tensile stress/ Tensile stress off shock	76/- Mpa
Breaking tensile strain	>50%
Compressive stress of normal strain-1%/2%	24/46 MPa
Pendulum gap impact test	5.5 KJ/m2
Rockwell hardness	M85
Dielectric strength	25 kv/mm
Volume resistance	10 14Ω×cm
Surface resistance	10 13Ω
Relative dielectric constant-100HZ/1MHz	3.9/3.3
Critical tracking index(CTI)	600
Bonding capacity	+
Food contact	+
Acid resistance	-
Alkali resistance	+
Carbonated water resistance	+/0
Aromatic compound resistance	+/0
Ketone resistance	+

Application

Pa6 Gf30 Sheet is widely used in IC parts, transport magazines, storage magazines, trays, straight balls, rollers, containers, pulleys, guide wheels, rollers, guides, parts for solvent treatment, parts for precision measuring devices, low frequency Electromagnetic wave sticker.

Goods Photo

PA6+GF Black Sheet

PA6+GF Black Board

Company Information

Our company has been established for more than 25 years and has the experience of producing a series of plastic semi-finished products. It introduces the most advanced imported equipment and combines the most advanced technology at home and abroad. The products are of high quality and low price, and the supply capacity is guaranteed.

Factory

Certification

certificate

Our Exhibition

AHD related products

Anheda produces a range of plastic products:PA6/PC/PU/POM/ABS/HDPE/PP sheet and rod;there are also a series of flame retardant / antistatic and other plastic products.
