UHD LED Displays High Gray Scale Without Flickering

UHD LED Displays High Gray Scale Without Flickering

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/Month
Supply Ability:	6000m²/Month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC FCC ETL CE EMC RoHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

Features&Advantages

1. Optional of aspect ratio of 16:9 or 4:3

2. Optional of Convex Shaped, Concave Shaped and Wave Shaped screens

3. High refresh rate to make it none of continuous flashing picture.

4. The indoor small-pitch LED display is equipped with a comfortable brightness to suit variety indoor lighting conditions and to meet the needs of the different crowd.

5. The high contrast ratio of 4000:1 makes the color of the screen more abundant, so that it is better for viewing it.

6. Low electric current and lower consumption but high quality lamps , which really saves energy.

7. Both the horizontal and the vertical viewing angle reach 140 degrees, which effectively ensures the viewing range and viewing effect of the audiences.

8. Automatic monitoring of internal temperature, voltage, then error detection.

9. It improve reliability and stability with distributed scanning(1/30 scan) technology and module design.

10. Excepted life time more than 50000 Hours, long standby.

Details

Model	IU-1.9
Pixel Pitch	1.92mm
Pixel Density	12,288px/m²
LED Type	SMD1010
LED Configuration	1R1G1B
Cabinet Dimension	400*300
Cabinet Resolution	208*156
Cabinet Weight	4.6kg/panel
Cabinet Material	die-casting
Ingress Protection(front/rear)	IP30
Brightness	>800nits
Contrast ratio	4000:1
Colours	281 trillion
Viewing Angle(H/V)	140°/140°
Driving Method	1/26 Scan
Power Consumption(avg.)	220w/m²
Power Consumption(max.)	800w/m²
Frame Refresh	≥ 60Hz
Data Refresh Rate	≥ 1500Hz
Gray Scale	16bit
Power Supply	AC 110/220±10% 50~60Hz
Temperature (operating/storage)	-20~50°C -40~60°C
Humidity(operating/storage)	10%~90%RH 10%~85%RH
MTBF	≥1000 Hours
Life Span	≥50000 Hours
Service	Front/Rear
Certification	CCC,TUV-CE,ETL

Details

Lightweight cabinet of led display

SMD1010 of fine pitch led display

FAQ
1. How many models are there in this series?
Yes, For indoor fine pitch HD led display we have P1.25mm P1.56mm P1.66mm P1.92 mm.

2. How about your warranty?
2 years warranty and lifetime maintenance

3. What's your delivery time?
Within 30 days after we receiving deposit.

4. What's your package and shipping way?
Goods are packed with wooden case or flight case; delivered by air shipping.road shipping or sea shipping

Tips
1.Package: Wooden package, Flight case.
2.Payment: T/T, 30% deposits, 70% balance before delivery
3.Shipping port: Shenzhen
4.Warranty time: 2years
5.Delivery time: 30 working days
