Multi-Angle Splicing Stage LED Display

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/month
Supply Ability:	6000m²/month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC,RoHS,CE,FCC,UL,ETL
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

Main feature:

Price lower than most factoryUltra slim and light cabinet, 85mm thickness, 13kg/cabient
Same cabinet have indoor and outdoor 2 series.
CNC Die-casting aluminium cabinet. Seamless assemble
Suit to all indoor and outdoor place.
Magnetic module accept front and back service

Application Places:

Ideal for super market, Shopping mall, hospital, bank, enterprises, government offices, exhibition hall, hotel,

sports stadium center, customs, staging area,car exhibition, airport, transportation, parks, TV

Specification

Model	ORD-7.8	ORD-10.4	ORD-15.6
Pixel Pitch	7.8125mm	10.416mm	15.625mm
Cabinet Dimension	500*1000mm	500*1000mm	500*1000mm
Cabinet Resolution	64*128px	48*96px	32*64px
Cabinet Weight	13kg	13kg	10kg
Cabinet Material	aluminum	aluminum	aluminum
Ingress Protection(front/rear)	IP65/IP54	IP65/IP54	IP65/IP54
Brightness	>5500nits	>5500nits	>5500nits
Viewing Angle(H/V)	140°/140°	140°/140°	140°/140°
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	>1500Hz	>1500Hz	>1500Hz
Gray Scale	16bit	16bit	16bit
Power Consumption(avg.)	420w/m2	300w/m2	320w/m2
Temperature(operating/storage)	-20~50°C / -40~60°C	-20~50°C / -40~60°C	-20~50°C / -40~60°C
MTBF	≥1000hrs	≥1000hrs	≥1000hrs
Life Span	≥100000hrs	≥100000hrs	≥100000hrs
Pixel Failure	<0.0003	<0.0003	<0.0003
