Outdoor Stage LED Display High Refresh

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/month
Supply Ability:	6000m²/month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC,FCC,ETL,CE,EMC,RoHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

Key Feature

Quick lock system, easy installation;High refresh rate and high contrast;Wide viewing angle;Working status indicator available;

Optional of Convex Shaped, Concave Shaped and Wave Shaped screens;

Ultra slim and lightweight;

Rental die-casting aluminum structure;Seamless splicing;

Quick lock system, easy installation;High refresh rate and high contrast;Wide viewing angle;Working status indicator available

Specification

Model	ORA-3.9	ORA-4.8	ORA-6.25
Pixel Pitch	3.9mm	4.8mm	6.25mm
Pixel Density	65536 pixels/m2	43264 pixels/m2	25600 pixels/m2
LED Type	SMD2525	SMD2727	SMD3535
LED Configuration	1R1G1B	1R1G1B	1R1G1B
Cabinet Dimension	500x500mm/500x1000mm	500x500mm/500x1000mm	500x500mm/500x1000mm
Cabinet Resolution	128128px/128256px	104104px/104208px	8080px/80160px
Cabinet Weight	8kg/14kg	8kg/14kg	8kg/14kg
Cabinet Material	die casting aluminum	die casting aluminum	die casting aluminum
Ingress Protection(front/rear)	IP65/IP54	IP65/IP54	IP65/IP54
Brightness	>6500nits	>6500nits	>6500nits
Viewing Angle(H/V)	140°/140°	140°/140°	140°/140°
Driving Method	1/8 Scan	1/13 Scan	1/10 Scan
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	>1500Hz	>1500Hz	>1500Hz
Gray Scale	16bit	16bit	16bit
Power Consumption(avg.)	420w/m²	420w/m²	420w/m²
Input Voltage	AC 110/220±10%, 50~60Hz	AC 110/220±10%, 50~60Hz	AC 110/220±10%, 50~60Hz
Temperature(operating/storage)	-20~50°C / -40~60°C	-20~50°C / -40~60°C	-20~50°C / -40~60°C
Humidity(operating/storage)	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH
MTBF	≥1000hrs	≥1000hrs	≥1000hrs
Life Span	≥100000hrs	≥100000hrs	≥100000hrs
Pixel Failure	<0.0003	<0.0003	<0.0003

Our Service

Pre-sales support:

1. We offered technical advice to you before buying our products.
2. Help you to choose suitable products within budget with most economy benefit.
3. Design the framework structure to install our led products with technical drawing.
4. We offered software customization for our your specific usage.

After- sales service:

1. We promise you more than just two years warranty service!
2.We provide free maintenance services including remote configuration, technical consultation, and trouble shooting for you.
3. We promise a life time follow-up service for all the equipment supply by our company.

These include continuously improve of system functions and upgrade of system software.
4. We offered training to our customer who includes operating and maintenance of our products.

Outdoor Stage LED Display
