Outdoor Stage LED Display High Refresh Rate

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Features:

1.Classic module design, superior product performance, stability.

2.Uniform color, high contrast, beautiful natural picture.

3.New perspective optimization design, covering the mainstream audience.

4.Anti UV, anti deformation module suite to protect the screen body deformation.

5.Patent design with unique color mask processing, showing the industry leading ultra high contrast.

6.Multiple waterproof casing design, single box full inspection factory, the protection level IP65 mature signal transmission architecture,

equipped with the upgraded version of power management technology, the use of more secure and reliable.

7.Patent design with unique color mask processing, showing the industry leading ultra high contrast.

8.Ultra low temperature free fan design, low temperature rise, small attenuation, long service life.

Specification

Model	ORA-3.9	ORA-4.8	ORA-6.25
Pixel Pitch	3.9mm	4.8mm	6.25mm
Pixel Density	65536 pixels/m2	43264 pixels/m2	25600 pixels/m2
LED Type	SMD2525	SMD2727	SMD3535
LED Configuration	1R1G1B	1R1G1B	1R1G1B
Cabinet Dimension	500x500mm/500x1000mm	500x500mm/500x1000mm	500x500mm/500x1000mm
Cabinet Resolution	128128px/128256px	104104px/104208px	8080px/80160px
Cabinet Weight	8kg/14kg	8kg/14kg	8kg/14kg
Cabinet Material	die casting aluminum	die casting aluminum	die casting aluminum
Ingress Protection(front/rear)	IP65/IP54	IP65/IP54	IP65/IP54
Brightness	>6500nits	>6500nits	>6500nits
Viewing Angle(H/V)	140°/140°	140°/140°	140°/140°
Driving Method	1/8 Scan	1/13 Scan	1/10 Scan
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	>1500Hz	>1500Hz	>1500Hz
Gray Scale	16bit	16bit	16bit
Power Consumption(avg.)	420w/m2	420w/m2	420w/m2
Input Voltage	AC 110/220±10%, 50~60Hz	AC 110/220±10%, 50~60Hz	AC 110/220±10%, 50~60Hz
Temperature(operating/storage)	-20~50°C / -40~60°C	-20~50°C / -40~60°C	-20~50°C / -40~60°C
Humidity(operating/storage)	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH	10%~90%RH / 10%~85%RH
MTBF	≥1000hrs	≥1000hrs	≥1000hrs
Life Span	≥100000hrs	≥100000hrs	≥100000hrs
Pixel Failure	<0.0003	<0.0003	<0.0003
