Light Weight 8kg/unit P2.98 Clear Image Quality

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Indoor SMD full color display using the latest generation technology,112896 points per square meter.

Meet customer requirements.High refresh frequency:Using the latest technology,makes use the ordinary general constant current(qure drive)

LED display with high refresh rate.

Eliminate screen flicker,phantom of the opera.

Key Feature

1.Optional of Convex Shaped, Concave Shaped and Wave Shaped screens;

2.Optional of Front service and rear service;

3.Front service module design, easy for maintenance;

4.Extremely close view distances and view angles;

5.Quick lock system allowing fast rigging;

6.Silent operation;

7.Excellent thermal management;

8.Lightweight and seamless;

Specification

Model	IRA-2.98
Pixel Pitch	2.98mm
Pixel Density	112896 pixels/m2
LED Type	SMD2121
LED Configuration	1R1G1B
Cabinet Dimension	500500mm/5001000mm
Cabinet Resolution	168168px/168336px
Cabinet Weight	8kg(13kg)
Cabinet Material	die casting aluminum
Ingress Protection(front/rear)	IP40/IP21
Brightness	>1200nits
Viewing Angle(H/V)	140°/140°
Driving Method	1/22 Scan
Frame Refresh	≥ 60Hz
Data Refresh Rate	>1500Hz
Gray Scale	16bit
Power Consumption(avg.)	320w/m2
Input Voltage	AC 110/220±10%/50~60Hz
Temperature(operating/storage)	-20~50°C / -40~60°C
Humidity(operating/storage)	10%~90%RH / 10%~85%RH
MTBF	≥1000hrs
Life Span	≥50000hrs
Pixel Failure	<0.0003
