Waterproof with IP65 Outdoor LED Display

Waterproof with IP65 Outdoor LED Display

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Incoterm:: FOB, CFR, CIF, EXW

Min. Order:: 1 Square Meter

Min. Order:: 1 Square Meter

Delivery Time:: 20 Days

Transportation:: Ocean, Air

Port:: Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	8000 M²/month
Supply Ability:	10000 M²/month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF,EXW
Certificate:	CCC.CE.ETL.FCC
Transportation:	Ocean,Air
Port:	Shenzhen

Product Description

Waterproof with IP65 Outdoor LED Display

BOR-I Series

Strength and Beauty

Outdoor Rental LED Display

Specification

	BOR-I-3	BOR-I-4	BOR-I-5	BOR-I-6
Physical Pitch	3.91mm	4.81 mm	5.95mm	6.25 mm
Pixel Configuration	SMD 1921	SMD 2525	SMD 2525	SMD 2727
Pixel Density	65536pixels/m²	43264 pixels/m²	28224 pixels/m²	25600 pixels/m²
Module Dimensions (W × H) (mm)	250 × 250 / 250×500	250 × 250 / 250×500	250 × 250 / 250×500	250 × 250 / 250×500
Panel Dimensions (mm)	500 × 500 × 80 / 500 × 1000 × 80	500 × 500 × 80 / 500 × 1000 × 80	500 × 500 × 80 / 500 × 1000 × 80	500 × 500 × 80 / 500 × 1000 × 80
NO .of Modules Per Panel (W × H)	2 × 2	2 × 2	2 × 2	2 × 2
Physical Resolution of Module (W × H)	64×64/64×128	52×52/52×104	42×42/42×84	40×40/40×80
Physical Resolution of Panel (W × H)	128×128/128×256	104×104/104×208	84×84/84×168	80×80/80×160
Panel Material	Die-Casting Aluminum	Die-Casting Aluminum	Die-Casting Aluminum	Die-Casting Aluminum
Single Cabinet Weight	9/ 15 kg/panel	9/ 15 kg/panel	9/ 15 kg/panel	9/ 15 kg/panel
Processing	16 bit	16 bit	16 bit	16 bit
Colours	281 trillion	281 trillion	281 trillion	281 trillion
Contrast Ratio	4,000 : 1	4,000 : 1	4,000 : 1	4,000 : 1
Average Power Consumption	75 /150 W/panel	75 /150 W/panel	75 /150 W/panel	75 /150 W/panel
Max Power Consumption	225 /550 W/panel	225 /550 W/panel	225 /550 W/panel	225 /550 W/panel
Operating Temp/Humidity	-20ºC - 60ºC / 10% - 60%	-20ºC - 60ºC / 10% - 60%	-20ºC - 60ºC / 10% - 60%	-20ºC - 60ºC / 10% - 60%
Storage Temp/Humidity	-30ºC - 60ºC / 10% - 60%	-30ºC - 60ºC / 10% - 60%	-30ºC - 60ºC / 10% - 60%	-30ºC - 60ºC / 10% - 60%
Refresh Rate	>1,920 Hz	>1,920 Hz	>1,920 Hz	>1,920 Hz
Brightness	>6000 nits	>6000 nits	>6000 nits	>6000 nits
Horizontal Viewing Angle	160°	160°	160°	160°
Vertical Viewing angle	140°	140°	140°	140°
Expected Lifetime	100, 000 Hrs	100, 000 Hrs	100, 000 Hrs	100, 000 Hrs
Max Stacking	20/10	20/10	20/10	20/10
Max Hanging	20/10	20/10	20/10	20/10
Servicing	Front / Rear	Front / Rear	Front / Rear	Front / Rear
IP Rating (Front/Rear)	IP 65/ IP 54	IP 65/ IP 54	IP 65/ IP 54	IP 65/ IP 54
Certification	CCC, CE, ETL, FCC	CCC, CE, ETL, FCC	CCC, CE, ETL, FCC	CCC, CE, ETL, FCC

Feature

Outdoor Rated
→ Outdoor waterproof with IP65
→ Suitable brightness adjustable for outdoor day and night
→ Deep black level, contrast ratio 4000:1

Fast Installation and Easy Maintenance
→ Truss hanging and ground support both available
→ Cable-less between modules
→ Front and rear access
→ Tools free installation

Slim,Light Weight and Quiet
→500mm×500mm or 500mm×1000mm options
→ 80mm thickness
→ Fanless design

Superior Electrical Features
→Dual signal backup port
→ UI LCD monitoring display indicates the status

Fast Installation

Company Introduction

Shenzhen BAKO VISION Technology Co.,Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding end professional customers among domestic and overseas markets.
Do not be hesitate to contact us if you have any quiry!

factory
