Indoor Fine Pitch LED Wall

Get Latest Price

Payment Type:: L/C, T/T, D/P

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/month
Supply Ability:	6000m²/month
Payment Type:	L/C,T/T,D/P
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC,CE,ETL,FCC,EMC,Rohs
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

UHD Series are adjust to various kind of indoor places,it can represent great images.

Application

Indoor advertising, Intdoor shows, entertainment occasion, event, stage, touring, show, festival, conference, exhibition, wedding, party, theme parks, etc.

Features

16 : 9 and 4 : 3 Format Options

Each cabinet is 400 x 300

16:9 or 4 : 3 free options

Available for any vedeo format

Fine Pitch LED Display

Ultra Slim and Light Panel

60mm thick panel with a weight of 4.6 KG pushs itself to the limit,which save cost of supporting structure and transportation

Indoor FIxed LED Panel

Convenient Maitenance

Module,power supply,receiving card can be maitained from the front,and front-accessible design reduces module replacement time to 5s

Indoor Fixed LED Wall

Excellent Display Effect

High refresh rate ,uniform color and 140° wide viewing angle

all guarantee an ultimate visual experience

Outdoor Rental LED Display

Parameter

Model	UHD-1.2	UHD-1.5	UHD-1.6	UHD-1.9
Pixel Pitch	1.25mm	1.56mm	1.66mm	1.92mm
Pixel Density	640000 pixels/m²	409600 pixels/m²	360000 pixels/m²	640000 pixels/m²
LED Type	SMD0909	SMD1010	SMD1010	SMD1010
LED Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Cabinet Dimension	400*300mm	400*300mm	400*300mm	400*300mm
Cabinet Resolution	320*240	256*192	240*180	208*156
Cabinet Weight	4.6kg	4.6kg	4.6kg	4.6kg
Cabinet Material	Die-casting	Die-casting	Die-casting	Die-casting
Ingress Protection (front/rear)	IP40/IP21	IP40/IP21	IP40/IP21	IP40/IP21
Brightness	>800nits	>800nits	>800nits	>800nits
Viewing Angle(H/V)	140°/140°	140°/140°	140°/140°	140°/140°
Driving Method	1/30 Scan	1/32 Scan	1/30 Scan	1/26 Scan
Power Consumption(avg.)	220w/m²	220w/m²	220w/m²	220w/m²
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	≥ 1500Hz	≥ 1500Hz	≥ 1500Hz	≥ 1500Hz
Gray Scale	16bit	16bit	16bit	16bit
Temperature (operating/storage)	-20~50°C -40~60°C	-20~50°C -40~60°C	-20~50°C -40~60°C	-20~50°C -40~60°C
Humidity(operating/storage)	10%~90%RH 10%~85%RH	10%~90%RH 10%~85%RH	10%~90%RH 10%~85%RH	10%~90%RH 10%~85%RH
MTBF	≥1000 Hours	≥1000 Hours	≥1000 Hours	≥1000 Hours
Life Span	≥50000 Hours	≥50000 Hours	≥50000 Hours	≥50000 Hours
Pixel Failure	<0.0003	<0.0003	<0.0003	<0.0003

FAQ

what is pixel pitch?

Pixel pitch is the distance between each LED cluster that makes a pixel pitch.

What the number in an IP rating means?

The first number indicates the degree of protection from solid objects.

The second number means protection against liquids

Our service

1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized needs we can help you to design and put into product
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
6.BAKO VISION can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.

Feedback:

1. We rely on our product quality and customer satisfaction to succeed. Therefore, your feedback is extremely important, please leave good feedback if you get satisfied with our goods and service.

2. We care about our valued customers, and will always try to help you. Please give us the opportunity to resolve any problem. We understand the concerns and frustrations you might have, and will try our best to resolve the issues.

3. Please email us before leaving any negative feedback or opening any dispute on the site. We will help you to resolve the problem.

Send your message to this supplier

* From:
* To:

Mr. Jack
* Messages:

Enter between 20 to 4,000 characters.

Related Keywords

Indoor Small PitchLED Panel , High Resolution LED Panel , Light Weight LED Display
