Easy Installation Outdoor Curved LED Display
  • Easy Installation Outdoor Curved LED Display
  • Easy Installation Outdoor Curved LED Display
  • Easy Installation Outdoor Curved LED Display
Easy Installation Outdoor Curved LED Display
Easy Installation Outdoor Curved LED Display
Easy Installation Outdoor Curved LED Display

Easy Installation Outdoor Curved LED Display

Payment Type:
L/C, T/T
Incoterm:
FOB, CFR, CIF, FCA, CPT
Min. Order:
1 Bag/Bags
Min. Order:
1 Bag/Bags
Delivery Time:
30 Days
Transportation:
Ocean, Land, Air
Port:
Shenzhen, Guangzhou
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Productivity: 6000m²/Month
Supply Ability: 6000m²
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,FCA,CPT
Certificate: CCC, FCC, ETL, CE, EMC, ROHS
HS Code: 8528591090
Transportation: Ocean,Land,Air
Port: Shenzhen,Guangzhou
Product Description
Product Description

Outdoor Curved LED Display is really popular in  the advertising industry.


Available range: school, shopping mall,stadium, commercial centers, government public announcement, commercial streets, and railway stations etc



Product Features


1.Optional of convex shaped,concave shaped and wave shaped screens

2.High gray scale and high refresh rate at even low brightness

3.Black LED's offer high contrast ratios and sharp images quality

4.Wide viewing angle up to140° (Horizontal and Vertical)

5.16bit(highest possible) color processing technology

6.Standard cabinet with seamless joint.

7.The cabinet can be operate in all-weather for its slim design and waterproofing that with a protection level of class IP65 in front and IP54 in back.


Versatile Dural Purpose Design

Cabinet can be reclined between 0-30 degree to ensure the best angle for audience and camera

Adding with ground adjustable bracket and protection foam bumper can be transformed to be perimeter dislay


Outdoor LED Display


Aging Test of Screen


Outdoor Curved LED Panel


Solution


Ourtdoor Curved LED Display


Parameter

Model

BDF-3

Pixel Pitch²

3.2 mm

Pixel Density

97,656 pixels/m²

LED Type

SMD3535

LED Configuration

1R1G1B

Cabinet Dimension

1024 × 768 × 100

Cabinet Resolution

293 × 295

Cabinet Weight

27.7kg

Cabinet Material

die casting aluminum

Ingress Protection(front/rear)

IP65/IP54

Brightness

2,500nits

Viewing Angle(H/V)

140°/140°

Driving Method

1/6 Scan

Frame Refresh

≥ 60Hz

Data Refresh Rate

>2000Hz

Gray Scale

16bit

Power Consumption(avg.)

300w/m²

Input Voltage

AC 110/220±10%,  50~60Hz

Temperature(operating/storage)

-20~50°C / -40~60°C

Humidity(operating/storage)

10%~90%RH / 10%~85%RH

Life Span

≥100000 Hrs
