P2.97 Indoor Rental Front Service LED Screen
  • P2.97 Indoor Rental Front Service LED Screen
  • P2.97 Indoor Rental Front Service LED Screen
  • P2.97 Indoor Rental Front Service LED Screen
P2.97 Indoor Rental Front Service LED Screen
P2.97 Indoor Rental Front Service LED Screen
P2.97 Indoor Rental Front Service LED Screen

P2.97 Indoor Rental Front Service LED Screen

Payment Type:
L/C, T/T, Paypal, Western Union
Incoterm:
FOB, CFR, CIF, FCA, CPT
Min. Order:
1 Square Meter
Min. Order:
1 Square Meter
Delivery Time:
Within 30 Days
Transportation:
Ocean, Land, Air
Port:
Shenzhen, Guangzhou
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Productivity: 6000sqm/month
Supply Ability: 6000sqm/month
Payment Type: L/C,T/T,Paypal,Western Union
Incoterm: FOB,CFR,CIF,FCA,CPT
Certificate: CCC,FCC,CE,ETL,RoHS,EMC
HS Code: 8528591090
Transportation: Ocean,Land,Air
Port: Shenzhen,Guangzhou
Product Description
Product Description

Indoor Rental Front Service LED Display with one single type module, can much reduce the cost for spare parts.Support front service, modules can be taken out without opening the back door,power suppliers are fixed without screws.At the bottom of cabinet, there is special design which can help to protect lamp during installation.


 front service led display

Description:



1.Modularization design. You can disassemble cabinets, modules and power supplies without any tools.



2.Curve installation is available.Inner and outer both up to 10°.



3.Dustproof and waterproof rating reached IP65 front side and IP54 rear side, can protect the screen from accidentally spilled drinks and rain, and guarantee the activities smoothly.



4.Excellent heat dissipation and noiselessness with ultra quiet fan.



5.Macromolecular flexible mask with glareless surface and better contrast ratio.



6.Intelligent LCD monitor for indicating working time and temperature.



7.RCFG file can be saved to factory. If you loose the RCFG file, just click" restore factory".

Stylish & elegant appearance design and ultra lightweight.



8.Automatic color calibration, larger viewing angle, wider range of audience, to meet the delicate color requirements.



9.Excellent thermal performance.



10.Save time:build quickly, fast maintain, easy to loading or unloading.



11.It`s not only pursuing the perfect appearance, but also for a better stage display effect: to make sure each circuit is well-arranged, each screw is solid and reliable; every process is tempered;our pursuit is to let each of your activities is vivid, beautiful and perfect.



12.It Controlled with PC by synchronization, with high refresh rate; an-synchronization control system is also available.

 fine pitch1



Specifications:



Model

BIR Series

Pixel Pitch

2.97mm

Pixel Density

112896 pixels/m²

LED Lamp Type

SMD2121

LED Configuration

1R1G1B

Cabinet Dimension

500*500mm
500*1000mm

Cabinet Resolution

168*168px
168*336px

Cabinet Weight

8kg(13kg)

Cabinet Material

die casting aluminum

Ingress Protection(front/rear)

IP40/IP21

Brightness

>1200nits

Viewing Angle(H/V)

140°/140°

Driving Method

1/22 Scan

Frame Refresh

≥ 60Hz

Data Refresh Rate

>1500Hz

Gray Scale

16bit

Power Consumption(avg.)

320w/m²

Input Voltage

AC 110/220±10%
50~60Hz

Temperature
(operating/storage)

-20~50°C / -40~60°C

Humidity
(operating/storage)

10%~90%RH / 10%~85%RH

MTBF

≥1000hrs

Life Span

≥50000hrs

Pixel Failure

<0.0003



outdoor led video

FAQ:

Q1. Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A:Sample needs 2-3 days, mass production time needs to be confirm.

Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available

Q4. How to order?
A:Please send us your purchase order by Email or we can make you proforma invoice under your request.
We need to know the following information for your order before sending you PI.
1)Product information-Quantity,Specification(Size,Material,Technological if needed and Packing requirements etc.
2)Delivery time required.
3)Shipping information-Company name,Street address,Phone&Fax number,Destination sea port.
4)Forwarder's contact details if there's any in China.

Q5. Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q6.  Do you offer guarantee for the products?
A: Yes, Lifetime warranty on hardware.
FREE Accessories Offering once ordered our items.
Please contact us whenever issues occur and we would try our best to assist.
