High Definition 4K LED Display For TV Studio

High Definition 4K LED Display For TV Studio

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/Month
Supply Ability:	6000m²/Month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC FCC ETL CE EMC RoHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

Specification
1. Whether front or rear maintenance, it is very simple and convenient, and it can also be used for single-point maintenance without disassembling the entire screen.

2. Applications:Control room,Meeting room, Airport Reception, Hall House of worship, Fashion store, Monitor Center, Opera House,TV studio, Video Conference,Restaurant,Shopping Malls

3.Dual backup power and signal lines to ensure the LED display works properly under any conditions.

4. Available for any video formats

5. Cable-less between modules

6. Unique color calibration process

7. Tight bin selection for led wavelength

8. Deep black levels,contrast ratio 4000:1

9. Flat cable free between module and cabinet to avoid signal missing.

10. Display effect without granular, food uniform color, no mosaic phenomenon.

11. Certification:CCC,TUV-CE,ETL,RoHS,EMC,UL

Details

Model	UHD-1.2	UHD-1.5	UHD-1.6	UHD-1.9
Pixel Pitch	1.25mm	1.56mm	1.66mm	1.92mm
Pixel Density	640,000px/m²	409,600px/m²	360,000px/m²	271,263px/m²
LED Type	SMD0909	SMD1010	SMD1010	SMD1010
LED Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Cabinet Dimension	400*300	400*300	400*300	400*300
Cabinet Resolution	320*240	256*192	180*120	208*156
Cabinet Weight	4.6kg/panel	4.6kg/panel	4.6kg/panel	4.6kg/panel
Cabinet Material	die-casting	die-casting	die-casting	die-casting
Ingress Protection(front/rear)	IP30	IP30	IP30	IP30
Brightness	>800nits	>800nits	>800nits	>800nits
Contrast ratio	4000:1	4000:1	4000:1	4000:1
Colours	281 trillion	281 trillion	281 trillion	281 trillion
Viewing Angle(H/V)	140°/140°	140°/140°	140°/140°	140°/140°
Driving Method	1/30 Scan	1/32 Scan	1/30 Scan	1/26 Scan
Power Consumption(avg.)	220w/m²	220w/m²	220w/m²	220w/m²
Power Consumption(max.)	800w/m²	800w/m²	800w/m²	800w/m²
Frame Refresh	≥ 60Hz	≥ 60Hz	≥ 60Hz	≥ 60Hz
Data Refresh Rate	≥ 1500Hz	≥ 1500Hz	≥ 1500Hz	≥ 1500Hz
Gray Scale	16bit	16bit	16bit	16bit
Power Supply	AC 110/220±10% 50~60Hz	AC 110/220±10% 50~60Hz	AC 110/220±10% 50~60Hz	AC 110/220±10% 50~60Hz
Temperature (operating/storage)	-20~50°C -40~60°C	-20~50°C -40~60°C	-20~50°C -40~60°C	-20~50°C -40~60°C
Humidity(operating/storage)	10%~90%RH 10%~85%RH	10%~90%RH 10%~85%RH	10%~90%RH 10%~85%RH	10%~90%RH 10%~85%RH
MTBF	≥1000 Hours	≥1000 Hours	≥1000 Hours	≥1000 Hours
Life Span	≥50000 Hours	≥50000 Hours	≥50000 Hours	≥50000 Hours
Service	Front/Rear	Front/Rear	Front/Rear	Front/Rear
Certification	CCC,TUV-CE,ETL	CCC,TUV-CE,ETL	CCC,TUV-CE,ETL	CCC,TUV-CE,ETL

Shows

Deep Black Levels wide viewing angle

Tips
* Package: Wooden package, Flight case.
* Shipment:By road,sea and air
* Delivery time:20-25 working days
* Payment: T/T, 30% deposits, 70% balance before delivery
* Shipping port: Shenzhen
* Warranty time: 2years
