JHY PCB provides a number of variants in rigid flex PCBs, which include 4 layer rigid-flex PCB with ENIG finish, 10 layer rigid-flex PCB with 4 layer flex, 12 layer rigid-flex PCB with heat sink, and many more. It is one of the leading rigid flex PCB manufacturers.

Rigid-Flex PCB designs are more challenging than the design of a typical rigid board environment, as these boards are designed in a 3D space, which also offers greater spatial efficiency. By being able to design in three dimensions rigid flex designers can twist, fold and roll the flexible board substrates to achieve their desired shape for the final application's package.

Rigid flex printed circuit boards (PCBs) are manufactured by combining rigid and flexible board technologies. These circuit boards are made up of multiple flexible circuit inner layers.

An epoxy pre-preg bonding film is used to attach together these inner layers. The key benefit of these boards is that they are a combination of the best quality of flexible and rigid circuit boards. This can have several further benefits as far as stability, assembly, signal transmission, and overall size of the circuit are concerned.
