Quick Turn and Small Quantity Prototype PCB Manufacturing

Circuit board prototyping services generally allow for a small quantity of boards to be manufactured and shipped quickly. Prototyping is ideal for rapid product development, pre-production design verification, and engineering projects.

What does Quick Turn Prototype PCB Manufacturing mean?

From sending design documents and production process requirements to PCB manufacturers, the factory can produce prototype PCB (for ordinary PCB boards) in about 8 hours from data processing to shipment.

If it is single-sided PCB, the limit time is about 4 hours, double-sided PCB about 8 hours, four-layer PCB about 24 hours, but the process can only be limited to tin spraying or gold deposition, the factory will be followed up by specialists, but relatively high cost.

Here, you can get fast quotation, fast manufacturing, fast delivery and so on, so as to shorten the time of PCB arrival at your hands as much as possible.

Moreover, there is no minimum quantity limit here. You can produce only one piece or 10 pieces. Follow up your needs. Fast turning to PCB production not only includes 2-12 layers of multi-layer circuit boards, but also other simple and complex PCB manufacturing services requiring a variety of production processes, such as Double-sided circuit boards, LED PCB, aluminum PCB, Rigid PCB, flexible PCB, HDI PCB or BGA PCB, etc.

At present, in order to meet the market demand, many PCB manufacturers have opened the PCB prototype fast turning to production services. Really achieved the urgent needs of users.

Quick Turn Prototype PCB Expedited Service requires an expedited fee

But the factory will charge some urgent fees for quick turn  PCB prototype production service. Because the acceleration is followed up and processed by specialists, it is necessary to ensure that the PCB is produced within the prescribed time. If you don't rush, the factory won't charge extra for it, so it depends on your demand at that time. There are 8 hours, 12 hours, 24 hours and 48 hours for your choice. If it's not urgent, it's recommended not to do urgent prototyping. Ordinary can also be produced in 3-4 days, which can save some development costs.

Why do we need quickly turn prototype PCB manufacturing?

The same is true for PCB prototype manufacturing. With flexible and turn quickly, we can test PCB design and products in the shortest time and speed up the pace of putting them into the market.

Another goal of rapid PCB prototyping is to screen out powerful PCB manufacturing plants to ensure the finished product rate and test pass rate of PCB production, to assess the approximate delivery time and quality, and to estimate accurately the situation of large-scale orders in the later period.

How long does it take for rapid turning to PCB prototyping?

Fast turning to PCB prototype manufacturing belongs to urgent service. How long will it take for quick turn PCB prototype production to deliver? It depends on the delivery time you choose. At present, there are 8 hours, 12 hours, 24 hours and 48 hours of urgent turning to PCB prototype manufacturing. If you choose 24 hours to make an urgent turning, you can place an order today and deliver it tomorrow evening. Choose 48 hours urgently, then place an order today and deliver the goods the night after tomorrow.

Here is a point that we need to pay special attention to: 24-hour rush, not delivery within 24 hours from the date you sent, but the order placed before 6 p.m. tonight and the order delivered tomorrow night, even if it was placed at 9 p.m. this morning, will also be shipped tomorrow evening. This is called 24-hour rush.

If you choose to rush for 8 hours, you can place the order in the morning and deliver the goods in the evening.

How to Choose Fast Turn PCB Manufacturers

Competition in the market is fierce, many factories also provide emergency services, but some factories because of equipment, supporting technology is not very mature, resulting in the final acceptance of customer requirements, but when the delivery time, but can not deliver, causing great losses to customers.

Therefore, when choosing a PCB manufacturer, we must find an enterprise with rich production experience and a set of quality management system that can control the production process and quality in an all-round way. It has advanced production equipment, advanced management level, and can deliver goods on time and with good credit.

Jinghongyi PCB, a Chinese PCB manufacturer specializing in PCB prototype manufacturing, small and medium-sized batch PCB production and PCB assembly, has rich PCB production experience, experienced engineers and skilled workers, advanced business management concepts, to provide affordable, cost-effective PCB manufacturing services.

Is the quick turn PCB prototype manufactured in China or elsewhere?

Fast turning to PCB prototyping has only two core purposes: saving time and money.

In China, there are many PCB manufacturers. We are one of them. At present, China has accounted for more than 50% of the world's PCB shipments. Therefore, China's PCB manufacturers will have more production experience, lower prices, higher quality, faster delivery time, which can also be based on. Some indicators are used to judge comprehensively:

* Speed. Delivery speed is very important. We have said more than once that time is money, and we cannot ignore the importance of fast weekly delivery. At JHYPCB, we will deliver your order on time without any delay.

* Efficiency. The services you receive from the manufacturer should be efficient and helpful to achieve your goals.

* Quality. The quality of products is very important. You should choose the manufacturer who can provide high quality products. Products should also meet the manufacturer's requirements and several standards.

* Price. Finally, the amount you pay for PCB is also important. Lower prices do not mean lower quality standards, but a reasonable cost-effectiveness.

Quick Prototype PCB, What does it mean for you?

• Speed is your advantage when competing with the big-boys.

• Reduce R&D time, and thus overall time-to-market

So, Quickturn Prototype PCB is your inevitable choice.

Quick Turn Prototype PCB, Use for production of low-volume quantities.

Contact us and let you know how competitive our PCBs are. Start now!

Whether you need just a few basic prototypes or a full production order, we`ll get boards in your hands fast.

Quick Turn PCB Prototype manufacturing capability

Learn more about JHY PCB by exploring the manufacturing capability of PCB Prototype below. We can do more than you can imagine.

Certification(UL:E466618, TS16949,  ISO9001.RoHS)

PCB Shipment

JHY PCB offers flexible shipping methods for our customers, you may choose from one of the methods below.

Shipping Process
After production and testing, your PCB orders will be sent to our shipping department. As the quick turn PCB manufacturer, JHY PCB shipping department will ship your PCB quickly without any pending.

JHY PCB 's Packing Way

• Use one professional PCB vacuum bag, with desiccant inside. Vacuum compressed totally.
• Paste label and RoHs mark. Use second vacuum bag to protect boards again, vacuum compressed, make sure no exception.
• Microsection report and Tin testing board are put together with PCB in cartons.COC (Certificate of Conformity)  will be sent to customer by email in PDF.
• Several layers of thick EPE(Expandable polyethylene) are filled fully in gaps between PCBs and cartons. Thickness of 1 layer EPE is 10mm.
• Neutral Packing is adopted if no special requirements. Strong and thick cartons(Thickness:10mm,7 layers). Different sizes of cartons are designed to meet demand of different PCB size. All package are within weight limit of cartons. For mass production order, no exceed 21kg per carton normally.
• All cartons sealed with strong adhesive tape should be sealed twice so as to make them more durable.
• Solid PP/PET strapping is used outside of cartons.
• Shipping mark, fragile mark and postcode label are all pasted clearly.
