10 Layer Shengyi Fr4 Material HDI PCB With ENIG

10 Layer Shengyi Fr4 Material HDI PCB With ENIG Surface Treatment

Keyword Tags: 10 Layer PCB,  Multilayer PCB, HDI PCB, Shengyi Fr4 Material PCB

Product parameters and technical details

• Layers: 10
• Thickness: 2.0±0.15 mm
• Material: Shengyi FR4
• Minimum aperture: 0.15mm
• Surface treatment: Immersion Gold
• Minimum line width/distance: 0.1mm/0.1mm
• BGA Size: 0.25mm
• Blind Via hole structure: 1-2 Layer, 2-3 Layer, 8-9 Layer, 9-10 Layer
• Process features: HDI Blind and buried via hole process, High Density BGA
• Application areas: high-definition security cameras, high-end communication equipment, multi-function POS machines, smartphones, multi-function walkie-talkies, driving recorders, industrial computers, industrial observers, smart
