Circuit Board Gold Fingers
In the realm of PCB assembly and manufacturing, there are three different methods that come with printing the prototype PCB`s legend. The legend is what the engineer uses to figure out the component designators, switch settings, and test points - all helpful components need when assembling, testing, and servicing the prototype circuit boards.
However, there are more details that go into this legend, including gold plating. Here is a beginner`s guide to this specific PCB fabrication process.
Gold finger is the gold-plated connectors that are on the edges of the printed circuit board prototype. They are similar to fingers in that they are long and narrow.
What are Circuit Board Gold Fingers made from?
The specifications for these have to be exact; flash gold must be used and the thickness cannot go over 3Us to 50Us. This is so the flash gold, which is one of the hardest golds available, will last a long amount of time and won`t need repair.
What is Circuit Board Gold Fingers purpose?
Gold fingers are edge connector contacts and are used to electroplate pads onto the board. The idea behind a gold finger is to help protect the printed circuit board prototypes from wear and tear. If applied correctly, with the right thickness, they are expected to last upwards of 1,000 cycles before there is any need of repair.
How are Circuit Board Gold Fingers used?
These little fingers are quite versatile, and they have many different uses depending on their intended purpose. Some of these uses include:
- Provides connections for network transfer data.
- Attaches specialty adaptors.
- Connects different devices to the board.
- Can be used as audio adaptors.
- Are there specific design specifications?
Yes. As we mentioned previously, there are some specifications depending on the need and use of the board. However, despite this, there are some design rules that must be followed no matter the board`s intended purpose. This includes:
- No plated through holes can be included anywhere near the gold fingers.
- No soldermask or screen printing can be included near the gold fingers.
- The gold fingers should always be placed facing outward of the board`s center.
Circuit Board Gold Fingers manufacturing service
The attributes of the displayed product
Type
Gold Fingers PCB
Layers
8L
Base Material
FR4 Tg170
Dielectric
Prepreg
Board Thickness
1.6mm±10%
Copper Weight
1oz
Surface Finish
ENIG 2U"+Gold Plating 45U"
Minimum trace Width/Spacing
0.13/0.13mm(5/5mils)
Solder Mask Color
Green
Silkscreen Color
White
Min. Hole Size
0.15mm
Hole Copper Wall Thickness
25.4um
Flame Retardant Properties
94 V-0
Application
Industrial Controllers
Why choose us?
- Save money&time! Achieve peace of mind!
- A professional and trustworthy PCB prototype manufacturer.
- Fastest PCB Prototype.
- One stop solution for various PCB&SMT Stencil.
- Low cost for simple PCB.
- Affordable price for high-tech PCB.
- Minimum orders 1pcs.
- 24-hour online customer service.
- Professional PCB engineer for one-to-one service.
- Shipment on time.
-
Guarantee good service and quality from PCB quotation to delivery.
Certification(UL:E466618, TS16949, ISO9001.RoHS)
Quality is one of the cornerstones in Global Success' business. We work actively with continuously improvements to secure a high quality level on our products as well as our services. To satisfy our customers we focus on producing PCB with stable top quality. We have implemented the UL:E466618, TS16949, ISO9001.RoHS quality system. The perfect quality assurance system and with various inspection equipment`s help us to monitor the whole production process, assure stability of this process and high product quality, meanwhile, advanced instruments and technology methods have been introduced to attain sustained improvement.
![]() |
![]() |
![]() |
