outdoor full color P8 SMD led display
Your message must be between 20 to 2000 characters
Contact NowOutdoor P8 SMD outdoor full color led display for advertising:
1. Top level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A raw material for module frame and mask
4. Four layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty.
8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
9 .Long ife span, more than 11 years.
Product Description
| Pixel pitch | P8 | ||
| Module Parameters | Pixel pitch | 8mm | |
| Pixel Density |
15625dots/m² |
||
| LED type | SMD 3535 | ||
| LED Configuration | 1R1G1B | ||
| Module Resolution | 40dots*20dots | ||
| Module Size | 320*160mm | ||
| Drive Method | 1/5 | ||
| Cabinet Parameters | Cabinet Resoltuion | 120dots*120dots | |
| Cabinet Size | 960*960mm | ||
| Cabinet Weight | 40KG | ||
|
Display Parameters |
Optical | Brightness | 5500CD/m² |
| Viewing angle | H/V 140/140 | ||
| Best Viewing Distance | 10-100 m | ||
| Grey Scale | 14 Bit | ||
| Power | Max power consumption | 678W/m² | |
| Ave power consumption | 226W/m² | ||
| Working Voltage | 220V / 110V | ||
| Reliability | Working Temperature | -20 to 60 ℃ | |
| Working Humidity | 10-95% RH | ||
| Life Span | 100,000 Hours | ||
| Pixel failing Rate | 0.002% | ||
| IP Rate | IP65 | ||
Advantages:
1.High Refresh Rate
2.High Brightness
3.Vivid Video Quality
4.Seamless Splicing
1.Reply enquiries in 24 hours.
2. Provide unique and professional solutions based on customer's requirement.
3.Market research and forecast for customer.
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service
1.Payment:T/T,30% deposits ,70% balance to be paid before delivering
2.By Air or Ship based on our customers' needs
3.Shipping port:ShenZhen,Mainland China
4.MOQ:1pc
