Outdoor full color led screen for fixed installation
Your message must be between 20 to 2000 characters
Contact Now|
Pixel Pitch
|
8mm
|
|
Pixel Resolution
|
15,625dots/m²
|
|
Module resolution
|
(W)40x (H)20 pixels
|
|
Module Size
|
(W)320mm x (H)160mm
|
|
Module weight
|
Around 490g
|
|
Driver Mode
|
Current Driving
|
|
Scan Mode
|
1/5
|
|
Operation Voltage
|
DC5V±10%
|
|
Max Module Current
|
Around 6.5A(typical)①
|
|
Max Power Consumption
|
Around 32.5W(typical)②
|
|
Power Interface
|
VH4
|
|
Signal Interface
|
HUB75
|
|
Max Brightness
|
≥6000cd/m²
|
|
Color Temperature
|
9500K
|
|
Viewing Angle(H/V)
|
120°/120°
|
|
Best Viewing Distance
|
8*80m
|
|
Grey Level
|
14bits
|
|
Brightness Calibration
|
supported
|
|
Refresh rate
|
≥1920Hz
|
|
Brightness Adjust Rang
|
0 to 255 adjustable
|
|
Life spam
|
100,000 Hour
|
|
Operation temperature
|
-20 ℃ ~ 60 ℃
|
|
Operation humidity
|
10%-90%RH without condensation
|
|
Stock temperature
|
-40 ℃ ~ 80 ℃
|
Shenzhen Joy LED Display Co., Ltd. is a LED electronic display and LED lighting application products. It is invested by three senior LED industry professionals in China. It integrates R&D, production, sales, engineering, and after-sales services. High-tech companies, adhering to the unique advantages in the field of LED display and control, the company has fullyintroduced the ISO9000 series quality management system, the production process in strict accordance with the requirements of RoHS and CE directives pay attention to every job details in the manufacturing process management Lean management, strive for perfection, is a medium-sized enterprise producing high-tech electronic display products.
