3.96mm Pin Header Single Row Dual Plastic Connector

Shenzhen Antenk Electronics Co., Ltd. launched a 3.96mm Pin Header Single Row Dual Plastic Straight Type electronic product

There are various types of pin headers, which can be roughly divided into 3.96mm, 2.54mm, 2.00mm, 1.27mm, 1.00mm, and 0.8mm according to the spacing (other special spacings can also be customized according to the needs); there are single rows according to the number of rows. Mother, double row mother, three rows, etc.; according to the package usage, there are patch SMT, plug-in DIP (straight insert / bend), etc.; at the same time, in order to match the corresponding pin header, you can order different sizes of mother-draft plastic.

   SPECIFICATION
Current Rating:                       7 Amp
Insulation Resistance:            1000M ohms min
Contact Resistance:               20M ohms max
Dielectric Withstanding:          AC500V
Operating Temperature:          -65°C  to  +125°C
Contact Material:                    Brass
Insulator Material:                  LCP,UL 94V-0 Black
