2.54mm FPC DIP straight connector

$500.00

≥1000 Bag/Bags

Min. Order:: 1000 Bag/Bags

Min. Order:: 1000 Bag/Bags

Transportation:: Ocean, Air, Express

Port:: SHENZHEN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	2000K/month
Supply Ability:	2000K/month
Payment Type:	T/T,Paypal
Incoterm:	FOB,CIF,EXW,FCA
Certificate:	ISO9001
HS Code:	8536909000
Transportation:	Ocean,Air,Express
Port:	SHENZHEN,

Product Description

2.54mm FPC DIP straight connector

MATERIAL
INSULATOR:Nylon 46,UL94V-0.
CONTACT:COPPER ALLOY.
PLATING:TIN PLATED OVER NICKEL.

SPECIFICATION
CURRENT RATING:1 AMP.
DIELECTRIC WITHSTANDING VOLTAGE:1000V AC MIN.
INSULATION RESISTANCE:5000MΩ MIN.
CONTACT RESISTANCE:25MΩ MAX.
VOTAGE RATING:AC,DC,50V(200Hz)

ENVIRONMENTAL
TEMPERATURE RANGE:-55°C TO +85°C

2.54mm FPC, NON ZIF,DIP straight FPC2.54-XXSTDXX1
